PreSonus Studio 1824 Overview
The Presonus Studio 1824 is a USB 2.0 audio/MIDI interface capable of recording up to 18 simultaneous inputs at up to 24-bit / 192 kHz and offers XMAX Class-A preamps, ADAT I/O, and S/PDIF I/O. Its 18 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with the included Studio One Artist for Mac and Windows, and UC Surface for Mac, Windows, iPad, and Android. The interface features a mute button, a mono button, two headphone outputs with independent mix streams, a BNC wordclock output, and MIDI I/O via a breakout cable.
- Input/Output
- Simultaneous I/O up to 18 inputs/18 outputs (8x8) at 192 kHz)
- 2 mic/instrument/line inputs with XMAX Class A mic preamps
- 6mic/line inputs with XMAX Class A mic preamps
- 8 channels of ADAT Optical input (4 channels at 96 kHz)
- Two balanced 1/4" TRS main outputs
- DC coupled for sending control voltages
- 8 balanced 1/4" TRS line outputs for monitor mixing
- DC coupled for sending control voltages
- 2 stereo headphone outputs with the same mix or independent mixes
- MIDI in/out
- Stereo S/PDIF digital I/O
- 1 USB 2.0 port
- BNC word clock output
- Integrated Software
- Studio One Artist for Mac and Windows
- UC Surface control software for Mac, Windows, iPad, and Android
- Meters, Controls, and Features
- 18x8 on-board DSP monitor mixer
- Front-panel level controls for main outputs
- Mono and Mute buttons for the main outputs
- True +48V phantom power for condenser microphones (global)
- 10 ladder-style, 8-LED level meters, (8 input, 2 main outputs)
- Digital
- 24-bit resolution
- 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- Physical
- 1RU rack-mountable
- Road-rugged construction with all-metal chassis and metal knobs
