In excellent shape, no cosmetic wear, and fully tested!

The Mackie 1402VLZ4 14-Channel Compact Mixer features Onyx preamps in a professional compact mixer used for applications that demand flexibility. From every input to every output, the mixer provides the highest headroom and lowest noise for maximum signal integrity.

The mixer is built-like-a-tank with a rugged solid-steel chassis and high-contrast controls for tactile control. With features like a dedicated control room section and smooth, accurate fader control, the 1402VLZ4 14-Channel Compact Mixer is a good choice for anybody who demands a professional performance.

Features:

- 14-Channel mixer featuring signature high-headroom, low-noise design

- 6 Boutique-Quality Onyx Microphone Preamps:
      Wide 60 dB gain range
      128.5 dB dynamic range
      +22 dBu line input handling
      Extended frequency response
      Distortion under 0.0007% (20 Hz to 50 kHz)

- Improved RF rejection, suitable for broadcast applications

- Phantom power for condenser microphones

- 14 High-headroom line inputs with +4/-10 operation control

- 3-Band EQ (80 Hz, & 2.5 and 12 kHz)

- 18 dB/octave 75 Hz low-cut filter on microphone input channels

- Two AUX sends, and level, pan, and PFL solo on each channel

- 60mm long-wearing log-taper faders

- Two stereo returns for connecting FX processor or other stereo source

- ALT 3/4 stereo bus for added routing flexibility

- Control room / phones source matrix

- High-resolution 12-segment stereo meters

- Sealed rotary controls resist dust and grime

- Built-like-a-tank rugged steel chassis with powder-coat finish

- High-visibility, high-contrast controls deliver convenient at-a-glance visual feedback

- Rack-mountable design using a rack ear kit (sold separately)

- Multi-voltage power supply for worldwide use

- Applications: Live sound mixing, houses of worship, clubs, gymnasiums, banquet halls, conference rooms, boardrooms, studio and field recording, multimedia applications, broadcast, and many more

Specifications:

Mixer

Number of Analog Input Channels: 14 (6 Mono / 4 Stereo)

Number of Mic Preamps: 6

Analog Output Channels

- 1x Stereo Master Output
- 1x Stereo Control Room/Monitor Output
- 1x Stereo Bus/Subgroup Output
- 2x Aux Send Output
- 1x Stereo Tape/Record Output
- 1x Stereo Headphone Output

Mix Routing

- Main Mix
- Aux Bus/Subgroup per Mono Input Channel, Stereo Input Channel

Faders & Level Adjustment

- 10x 2.4" / 60 mm Channel Fader
- 1x 2.4" / 60 mm Bus/Subgroup Fader
- 2x 2.4" / 60 mm Master Fader

Signal Processing

Gain/Trim Range: 0 dB to +60 dB

Dynamic Processing: No

EQ

- Input Channels:
- 3-Band EQ

EQ Parameters

- High: ±15 dB at 12 kHz (Shelving)
- Mid: ±15 dB at 2.5 kHz (Notch/Peak)
- Low: ±15 dB at 80 Hz (Shelving)

 Graphic EQ: No

Filters

- High-Pass: 75 Hz, 18 dB/Octave

Solo/Mute: Solo, Mute per Input Channel

Built-In Effects: No

Performance

Frequency Response

- Mic Input to Main Output: 20 Hz to 50 kHz +0/-1 dB (Unity Gain)
10 Hz to 100 kHz +0/-3 dB (Unity Gain)

Max Input Level

- Mic Input: +22 dBu
- Tape Input: +16 dBu
- Line Input: +22 dBu

I/O Impedance

- Mic Input: 2.5 Kilohms
- Insert Return: 2.5 Kilohms
- Line Input: ≥ 10 Kilohms
- Tape Output: 1.1 Kilohms
- Main Output: 120 Ohms

 Noise Floor

- -101 dBu (Master Level at -∞, Channel Levels at -∞)
- -91 dBu (Master Level at Unity, Channel Levels at -∞, 95 dB SNR, Ref +4 dBu)
- -86 dBu (Master Level at Unity, Channel Levels at Unity)

 THD

- Mic Input to Insert Send: < 0.0007% at +35 dB Gain (1 kHz) \

Connectivity

Analog Inputs

- 6x XLR 3-Pin Balanced Mic Input
- 6x 1/4" TRS Unbalanced Line Input
- 8x 1/4" TRS Unbalanced Stereo Line Input (4 Stereo Pairs)
- 6x 1/4" TRS Insert Input (Pre-Fader)
- 2x RCA Tape Input (1 Stereo Pair)
- 4x 1/4" TRS Stereo Aux Return (2 Stereo Pair)

Analog Outputs

- 2x 1/4" TRS Stereo Main Output
- 1x 1/4" TRS Stereo Headphone Output
- 2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair)
- 2x 1/4" TRS Balanced/Unbalanced Stereo Control Room Output
- 2x 1/4" TRS Balanced/Unbalanced Stereo Alt Output (1 Stereo Pair)
- 2x RCA Unbalanced Stereo Tape Output (1 Stereo Pair)
- 2x 1/4" TRS Balanced/Unbalanced Stereo Aux Send

Phantom Power: +48 V

Digital I/O: No

Wireless: No

Power

AC Input Power: 100 to 120 VAC, 50 / 60 Hz (T 500 mA 250 V)

Physical

Operating Conditions: 32 to 104°F / 0 to 40°C

Dimensions: 12.5 x 14 x 3.2" / 317 x 356 x 81 mm

Weight: 9.5 lb / 4.5 kg
