Hotly anticipated rotary goodness from Spanish pro audio specialists Ecler. Simple, pure two-channel design with three-band channel EQs, three-band isolator and quality sound. Supplier's Notes: Two-Channel Analogue Rotary Mixer WARM2 is a professional two-channel analogue rotary DJ mixer, designed and manufactured by ECLER in Barcelona. Featuring two phono/line channels and a micro/line channel, classic sharp filters, a 4th order Isolator and a narrow portable format, it will deliver a warm and crystal clear analogue sound. Audio Performances Inputs Sensitivity nom/Impedance: LINE : 0dBV/50kO PHONO : -40dBV/50kO MICRO : -50dBV/>1kO FX RETURN : 0dBV/>6kO Outputs Level/Minimum Load: HOUSE (BAL) : 0dBV/600O 1V *(+12dB 4V) HOUSE (UNBAL) : 0dBV/2.2kO 1V *(+12dB 4V) BOOTH (UNBAL) : 0dBV/2.2kO 1V *(+12dB 4V) REC : 0dBV/10kO HEADPHONES : 200mO/200O THD 1% FX SEND : 0dBV/2.2kO Frequency Response: LINE : 10Hz#30kHz -1dB MICRO : 10Hz#25kHz -1dB PHONO : RIAA i0.5dB FX RETURN : 10Hz#50kHz -1dB THD-N: LINE : <0.006% MICRO : <0.9% PHONO : <0.08% FX RETURN : <0.005% CM MR: MICRO: >70dB @ 1kHz Signal Noise Ratio: LINE: >99dB MICRO: >85dB PHONO: >98dB FX RETURN: >100dB Max Undistorted Output Level: HOUSE (Electr.BAL): 21dBV (23dBu) HOUSE (UNBAL): 21dBV (23dBu) BOOTH (UNBAL): 21dBV (23dBu) Trim control: INPUTS 1-2: - 15dB INPUT 3: - 20dB Tone control Inputs 1-2: BASS: +10/-30dB MID: +10/-25dB TREBLE: +10/-30dB Tone control Isolator: BASS: +12/-70dB MID: +12/-40dB TREBLE: +12/-70dB Tone Filter cut frequency at -6dB (slope 12dB/oct): BASS: 200Hz MID: 200Hz#6.8kHz TREBLE: 6.8kHz Isolator cut frequency at -6dB (slope 24dB/oct): BASS: 300Hz MID: 300Hz#4kHz TREBLE: 4kHz Connectors Inputs: LINE 1-2-3: RCA STEREO PHONO 1-2: RCA STEREO MICRO 3: 6.3mm TRS BAL. JACK FX RETURN: RCA STEREO Outputs: HOUSE (BAL): XLR STEREO HOUSE (UNBAL): RCA STEREO BOOTH: RCA STEREO FX SEND: RCA STEREO REC: RCA STEREO HEADPHONES: 6.3mm/3.5mm STEREO JACK Miscellaneous Control Mode: Rotary with Alps Blue Velvet Potentiometers Phantom Voltage: 18VDC/5mA Max (Default ON) MIX and PFL VU-Meter: LED 12 segments (-30dBV # +20dBV) Operation Operation Temperature: -5-C - 45-C / 23-F - 113-F Humidity: 20 - 90% RH (no condensation) Supply Mains voltage: 90-264VAC 47-63Hz Rated power consumption: 30VA Mechanical Dimensions (without wooden sides): 400 x 185 x 100mm / 15.7" x 7.2" x 3.9" Weight : 3.6Kg / 7.94 lbs
