Blastking ULTRAMIX-164FX 16-Channel Mixer with 4 Aux, Bluetooth, USB and DSP

Brand-new Blastking ULTRAMIX-164FX professional 16-channel mixing console.

The ULTRAMIX-164FX combines 16 low-noise, high-headroom input channels, four auxiliary sends, four subgroups, Bluetooth®, USB playback and recording, a PC audio interface, and a 24-preset digital effects processor.

Designed for live sound, bands, houses of worship, venues, events, studios, presentations, and permanent installations, this console offers flexible signal routing and detailed control in a durable professional format.

Each channel features a high-quality XLR/1/4-inch combination input, a wide 60 dB gain range, +22 dBu line-input capacity, smooth 100 mm faders, four-band EQ, and +48V phantom power for compatible condenser microphones.

The integrated 24-bit/40 kHz effects processor includes reverbs, delays, vocal and karaoke echoes, modulation effects, distortion, pitch change, and other useful live-sound presets.

KEY FEATURES

• Professional 16-channel mixing console
• Low-noise, high-headroom input channels
• XLR/1/4-inch combination input connectors
• Four auxiliary sends
• Four subgroups
• Wide 60 dB gain range
• +22 dBu line-input capacity
• Smooth, low-noise 100 mm faders
• High-precision four-band channel EQ
• Sweepable midrange frequency from 250 Hz to 5 kHz
• Seven-band ±12 dB graphic equalizer
• +48V phantom power on each channel
• 24-bit/40 kHz digital effects processor
• 24 integrated effects presets
• Built-in Bluetooth®
• USB media player and recorder
• PC audio-interface functionality
• Stereo RCA recording outputs
• RCA two-track inputs
• Stereo headphone output
• Stereo control-room output
• Sealed rotary controls that resist dust and grime
• Multi-voltage power supply
• Two-year manufacturer warranty
• Designed in the USA

TECHNICAL SPECIFICATIONS

Brand: Blastking
Model: ULTRAMIX-164FX
Type: Professional analog mixing console
Input channels: 16
Input connectors: XLR/1/4-inch combination connectors
Auxiliary sends: 4
Subgroups: 4
Gain range: 60 dB
Line-input capacity: +22 dBu
Channel faders: 100 mm
Channel EQ: Four-band
EQ frequencies: 80 Hz, sweepable 250 Hz–5 kHz, 2.5 kHz, and 12 kHz
Graphic equalizer: Seven-band, ±12 dB
Phantom power: +48V on each channel
Digital processor: 24-bit/40 kHz
Effects presets: 24
Bluetooth: Integrated
USB functions: Media playback and recording
Computer connection: PC audio interface
Record outputs: Stereo RCA
Two-track inputs: RCA
Headphone output: Stereo
Control-room output: Stereo
Distortion: Less than 0.0007% from 20 Hz–50 kHz
Power supply: Multi-voltage
UPC: 686811894917

INTEGRATED EFFECTS

1. Reverb Hall 1
2. Reverb Hall 2
3. Reverb Room 1
4. Reverb Room 2
5. Reverb Stage 1
6. Reverb Stage 2
7. Plate Reverb
8. Drum Ambience
9. Early Reflection
10. Gate Reverb
11. Single Delay
12. Delay
13. Vocal Echo
14. Karaoke Echo
15. Phaser
16. Flanger
17. Chorus 1
18. Chorus 2
19. Ping-Pong Delay
20. Tremolo
21. Auto Wah
22. Radio Voice
23. Distortion
24. Pitch Change

PHYSICAL SPECIFICATIONS

Dimensions: 28 × 4.5 × 17 inches / 71.1 × 11.4 × 43.2 cm
Net weight: 20 lb / 9 kg

PACKAGED SPECIFICATIONS

Dimensions: 31 × 7 × 20 inches / 78.7 × 17.8 × 50.8 cm
Shipping weight: 26 lb / 11.8 kg

WHAT IS INCLUDED

• One Blastking ULTRAMIX-164FX mixing console
• Power cable
• Original manufacturer packaging

CONDITION

Brand new and unused, supplied by Blastking USA. The mixer includes its original manufacturer packaging and is covered by the manufacturer’s two-year warranty.

This listing is for one mixing console. Microphones, audio cables, computers, powered speakers, headphones, instruments, racks, and other equipment are not included unless specifically shown and stated as included.
