The MGX12 B is a compact digital mixing console engineered for professional audio performance in a streamlined format. It delivers premium sound quality, flexible I/O, and intuitive control through a touchscreen interface and dedicated hardware controls. Ideal for live sound, streaming, installed systems, and recording, the MGX12 B adapts easily to diverse workflows while maintaining consistent, high-quality results.

Yamaha MGX12 B Includes

• MGX12 B digital mixer
• Power adapter (PA-300C)
• Start Guide and Safety Guide
• Steinberg software license (Cubase AI, WaveLab Cast LE, Basic FX Suite, Steinberg Plus)

Yamaha MGX12 B Features

• 18-channel digital mixing console
• 11 + 1 non-motorized fader configuration
• 4.3-inch touchscreen with five assignable control knobs
• Dual USB-C audio interface for recording and playback
• Built-in DSP for professional effects and latency-free monitoring
• Bluetooth® audio input (Bluetooth 5.0, A2DP)
• Standalone multitrack recording via microSD card
• Assistive tools including Auto Gain, Clip Safe, and Scene Recall

Yamaha MGX12 B Specifications

• Input Channels: 4 mono + 4 stereo + 1 Sound Pad + 2 FX returns
• Busses: 8 Mix + 2 FX + 1 Cue + 1 Stereo
• Local Inputs:
  • 4 Mic/Line (XLR/TRS combo)
  • 8 Line (4 TRS, 4 RCA)
• Local Outputs: 2 XLR, 6 TRS, 4 headphone outputs
• USB Main: 18 inputs / 18 outputs, 32-bit / 96 kHz
• USB Sub: 2 inputs / 2 outputs, 16-bit / 48 kHz
• Bluetooth Audio: 2-channel input
• microSD Card: 16-track recording / 2-track playback (up to 24-bit / 96 kHz)
• Dimensions (HxWxD): 3.8" × 13.2" × 12.5" (95.4 × 335 × 318.4 mm)
• Weight: 8.6 lb (3.9 kg)
• Finish: Black
