Modular Dual Capsule Condenser Microphone

The e70 microphones are audio tested and inspected under the direction of CAD Professional Microphones, offering an exceptional level of value.

Key Features

• Packaged in a small, rugged metal housing, the equitek e70 condenser microphone provides transparent, accurate acoustic capture
• The low mass 1/2" gold sputtered diaphragm makes the e70 the preferred choice for high frequency sources rich in transients such as cymbal, hi-hat, strings, acoustic guitar, woodwinds and piano
• The transformerless design reduces low frequency distortion at high sound pressure levels
• The 3 position hi-pass filter and 3 position pad provide the versatility required in demanding live sound and studio applications
• The interchangeable capsules provide both cardioid and omnidirectional pickup patterns for greater flexibility
• The e70's accuracy, high SPL capability and size make it a valuable tool in the professional audio environment

Technical Specifications

Type
End address condenser with interchangeable capsules
Frequency Response
20Hz - 20KHz
Impedance
85 ohms
Using Cardioid Capsule
Sensitivity: -40dBV (10mV) @ 1 Pa
Self Noise: 23dB, A-weighted
Maximum SPL: 155dB, 20dB pad engaged
Using Omnidirectional Capsule:
Sensitivity: -36dBV (16mV) @1 Pa
Self Noise: 19dB, A-weighted
Maximum SPL: 154dB, 20dB pad engaged
Power Requirements:
Phantom P48, 2mA
Connector
Three pin XLR type
Polarity
Inward pressure on the diaphragm produces positive voltage on pin 2
Dimensions
7/8" (22 mm) x 6 1/8" (156 mm)
Net Weight
7.6 oz. (216 grams).
Included Accessories
Shockmount, mic clip and windscreen
