T-Bar Under-Saddle Pickup

The Ibanez under-saddle pickup reduces noise and provides wide range of natural piezo-style sound. It also captures palm hits and delivers a bass drum-like response.

Block Contact Pickup

Since it’s placed on the neck block, the Ibanez contact pickup is resistant to feedback and evenly captures percussive sound from the body to the neck. It also adds air and brightness to the piezo-style sound by capturing acoustic tones from within the body.

Ibanez DP1 Preamp

The DP1 Preamp naturally amplifies the signal from the Dual Pickups. You can precisely blend the sound of both pickups using the simple control layout (Under-saddle pickup volume / Contact pickup volume), which reduces added holes in the body to maintain tonal integrity.

Dual Outputs

Plugged into the endpin jack only : Under-saddle pickup + Contact pickup with mixed output

Plugged into both the endpin jack and the open jack : Under-saddle pickup and Contact pickup running independently.

Endpin Jack : Under-saddle pickup Output

Open Jack : Contact Pickup Output

Shallower Dreadnought Body

The body depth of the Dreadnought model is 8mm shallower-than-standard which generates a crisp yet full-bodied sound for percussive or strumming playing styles.

African Mahogany/Pau Ferro 5pc Neck

5pc neck construction boasts increased stability for alternate tunings.

Deep Round Neck Heel

The deep, round neck heel construction makes playing more comfortable in the higher register.

Neck Grip

The combination of a 45mm wide nut and thin C shape neck is ideal for the complex fretting and arpeggios of Fingerstyle.

Unbleached Oil-impregnated Bone nut and saddle

The unbleached oil-impregnated nut and saddle deliver strong consistent string vibration and better tuning stability due to decreased friction resistance.

Open Pore Finish

The thinner open pore finish highlights the texture of the wood and emphasizes the acoustic and percussive tonal properties of the instrument.

Ibanez Advantage Bridge Pins

These pins really are an advantage over old-fashioned pins. Advantage pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage the pin and string stay put.

Features

• Body Shape : Cutaway Dreadnought Body (Shallower Body Depth) Body
• Bracing : Scalloped X Bracing
• Top : Solid Engelmann Spruce Top
• Back & Sides : Okoume Back & Okoume Sides
• Neck : Thin C Shape W/Rounded Fretboard Edgeafrican Mahogany/Pau Ferro 5pc Neck
• Fretboard : Macassar Ebony Fretboard
• Bridge : Macassar Ebony
• Top Board Purfling : Wooden
• Soundhole Rosette : Pau Ferro Rosette W/Soundhole Binding
• Tuning Machine : Chrome Die-Cast Tuners
• Nut Material : Unbleached Oil-Impregnated Bone
• Number Of Frets : 20
• Saddle Material : Unbleached Oil-Impregnated Bone
• Bridge Pins : Ibanez Advantage
• Strings : Elixir Strings Nanoweb Phosphor Bronze, Light
• String Gauge : .012/.016/.024/.032/.042/.053
• String Space : 11mm
• Factory Tuning : 1E,2B,3G,4D,5A,6E
• Pickup : Ibanez T-Bar Undersaddle & Block Contact Pickup
• Preamp : Ibanez DP1 Preamp
• Output Jack : Dual Outputs (Mono Out / Stereo Out)

Neck Dimensions

• Scale : 651mm
• A : Width : 45mm At NUT
• B : Width : 56mm At 14F
• C : Thickness : 20.5mm At 1F
• D : Thickness : 21.5mm At 7F
• Radius : 400mmr

Body Dimensions

• A : Length : 20 "
• B : Width : 15 3/4"
• C : Max Depth : 4 5/8"
