Next-Generation Acoustic Performance Engineered for the Stage

Known for over four decades as the premier pioneers in acoustic amplification under the iconic L.R. Baggs name, Baggs enters a bold new era with the AEG-1 Acoustic-Electric Guitar. Designed ground-up for gigging musicians and studio professionals, the AEG-1 bridges the gap between authentic acoustic resonance and feedback-free high-volume electric stage performance.

Featuring a hand-selected torrefied Sitka spruce top paired with a hollowed mahogany back and sides, the AEG-1 delivers the airy warmth, touch sensitivity, and harmonic richness of a fine acoustic instrument. Its chambered, thin-line body contour completely eliminates the resonant feedback loops typical of traditional dreadnoughts and grand auditoriums on loud stages—giving you total acoustic freedom without compromise.

Proprietary Acoustic Equalization System & HiFi Electronics

At the heart of the AEG-1 is Baggs' revolutionary onboard Acoustic Equalization System paired with their acclaimed multi-sensor HiFi pickup system. Rather than relying on harsh piezo quack or delicate internal mics, the internal preamp system captures the natural acoustic energy of the soundboard with studio-grade depth, immediate transient response, and pristine clarity through any PA system or acoustic amplifier platform.

Technical Specifications:

• Top Wood: Solid Torrefied Sitka Spruce (Sunburst Gloss Finish)
• Body Construction: Chambered Solid Mahogany Back and Sides
• Neck Profile: Ergonomic Modern C-Shape Mahogany Neck with Satin Finish
• Fretboard: Premium Ebony Fingerboard with Low-Profile Frets
• Electronics: Integrated Baggs HiFi Multi-Sensor Pickup System with Acoustic Equalization Controls
• Bridge: Solid Ebony Bridge with Precision Engineered Saddle
• Hardware: High-Ratio Tuning Machines for Rock-Solid Tuning Stability
• Protection: Heavy-Duty Deluxe Padded Gig Bag Included

Sanctuary Expert Note:

The Baggs AEG-1 is a game-changer for gigging acoustic artists. If you perform with a full band, push high stage volumes, or record direct-to-interface, this guitar provides true acoustic air and dynamic response with zero feedback headaches.

GUITAR SPECIFICATIONS

Guitar Description: High-performance Acoustic Electric Guitar
Back Woods: Indian Rosewood
Side Woods: Composite Poplar frame
Top Wood (A): Engelmann Spruce (Natural)  THIS MODEL
Top Wood (B): Torrefied Sitka Spruce (Torrefied)
Top Wood (C): Sitka Spruce (Sun Burst)
Top Finish: Gloss
Color: Natural, Torrefied, Sun Burst
Body Bracing: Scalloped X Bracing
Neck Wood: African Mahogany
Neck Shape: Slim “C” shape
Fingerboard Radius: 16”
Fingerboard Material: Indian Rosewood
Fingerboard Inlay: Wood fret markers
Number of Frets: 20
Scale Length: 25-5/8” (651mm)
Nut Width: 1.7” (43mm)
Nut/Saddle Material: Composite
Bridge Material: Indian Rosewood
Tuning Machines: Closed backed tuners

ELECTRONICS SPECIFICATIONS

Pickup System: Custom HiFi Duet with HiFi Pickups and Silo Microphone
Battery: Single 9V
Current Consumption: 4.1mA
Battery Life: 120Hrs
Input impedance:
- Pickup (High) 4.7MEG
- Pickup (Low) 4.7MEG
Mic: 6.8K
Output Impedance: 3.6K
