This reel to reel tape deck is in good working order, fully tested and cleaned by our service technician, who has noted the following:
1) The unit is fully functional, however the heads are not in excellent shape, and could use a re-lap in the not too distant future- it plays and sounds alright now, though. 2) There is some pitting present as well.
As such, the unit is sold as-is, guaranteed to be working but with no warranty.
The X-2000R incorporates a variety of functions and features including dbx noise reduction, an auto-locator function which is convenient in replay and editing and block-repeat.
To maintain very stable tape motion with optimum tape tension, it uses a full tension servo control system in which a photo-interrupter senses the position of the tension arm so that the servo mechanism can adjust the torque of the reel motor.
This mechanism eliminates the need for manual switching when using different types of reels.
In the design of the electronic circuits the same concepts were applied, especially for the high level recording required by professionals.
Specifications:
1) The unit is fully functional, however the heads are not in excellent shape, and could use a re-lap in the not too distant future- it plays and sounds alright now, though. 2) There is some pitting present as well.
As such, the unit is sold as-is, guaranteed to be working but with no warranty.
The X-2000R incorporates a variety of functions and features including dbx noise reduction, an auto-locator function which is convenient in replay and editing and block-repeat.
To maintain very stable tape motion with optimum tape tension, it uses a full tension servo control system in which a photo-interrupter senses the position of the tension arm so that the servo mechanism can adjust the torque of the reel motor.
This mechanism eliminates the need for manual switching when using different types of reels.
In the design of the electronic circuits the same concepts were applied, especially for the high level recording required by professionals.
Specifications:
Track system: auto reverse, 4-track, 2-channel, stereo/monaural system
Heads: 2 x playback, 2 x record, 2 x erase
Motor: 2 x reel, 1 x capstan
Reel size: up to 10.5 inch reel
Tape speeds: 3 3⁄4 7 1⁄2 ips
Wow and flutter: 0.03% (7 1⁄2 ips)
Frequency response: 30Hz to 40kHz (7 1⁄2 ips)
Signal to Noise Ratio: 63dB
Total harmonic distortion: 0.8%
Input: 60mV (line), 0.25mV (mic)
Output: 0.45V (line)
Dimensions: 432 x 456 x 268mm
Weight: 21kg
