For 30 years the SR has given bass players a modern alternative. With its continued popularity, Ibanez is constantly endeavoring to answer the wider needs of a variety of players, at a variety of budgets. But no matter what the specs, the heart is the same-SR continues to excite with its smooth, fast neck, lightweight body, and perfectly matched electronics.

Features

5pc Maple/Rosewood neck

The SR neck is famous for its slim easy-to-play profile. The 5pc Maple/Rosewood construction provides excellent strength and stability while enhancing sustain.

PowerSpan Dual Coil pickups

Developed by Ibanez, the exposed pole pieces of the PowerSpan Dual Coil pickups produce a stronger signal, and increase the response of the higher frequencies without sacrificing low end. The result is a tone rich in harmonic detail and dynamic expression.

Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch

The 3-band EQ works in conjunction with a coil tap switch for maximum control over a wide variety of professional bass tones. Tap Mode (single coil) creates a punchy, dynamic sound with superior articulation. Series Mode (humbucking) delivers a full, warm tone, and Power Tap Mode provides the best of both worlds-combining the clarity of the single coil with the fat bottom end of the humbucker.

Accu-cast B120 Bridge

The B120's extra-wide string slots can accommodate even the heaviest of gauges. Walls and channels of the new bridge plate effectively "trap" the saddles, ensuring perfect directional uniformity.

Specifications

neck type: SR5 5pc Maple/Rosewood neck
body: Mahogany body
fretboard: Rosewood fretboard w/White dot inlay
fret: Medium frets
number of frets: 24
bridge: Accu-cast B125 bridge (16.5mm string spacing)
neck pickup: PowerSpan Dual Coil neck pickup (Passive)
bridge pickup: PowerSpan Dual Coil bridge pickup (Passive)
equaliser: Ibanez Custom Electronics 3-band EQ w/3 way Power Tap switch
factory tuning: 1G, 2D, 3A, 4E, 5B
string gauge: .045/.065/.085/.105/.130
hardware color: Cosmo black

Neck Dimensions

Scale : 864mm/34"
a : Width 45mm at NUT
b : Width 68mm at 24F
c : Thickness 19.5mm at 1F
d : Thickness 21.5mm at 12F
Radius : 305mmR
