BLACK LION AUDIO REVOLITION 2X2 AUDIO INTERFACE - BSTOCK

WE HAVE AN EX DEMO REVOLUTION 2X2 FOR SALE IN GREAT CONDITION AS SHOWN IN THE LISTING. ITEM COMES WITH ORIGINAL PACKAGING AND 6 MONTHS WARRANTY FOR PEACE OF MIND. FREE POSTAGE TO UK MAINLAND ONLY. FURTHER PRODUCT INFO BELOW:-

The Revolution is here.

Black Lion Audio have been revered as the “king of audio mods” for years, and have modded countless recording interfaces over the years. But since the very beginning, we’ve been asked when we would create our own interface. So, we planned, engineered, and worked — all in secret, for years.
It took an impressive amount of design to revolutionize bus-powered, studio-grade interfaces. Now we are responding with Revolution 2x2: the ultimate in portable recording interfaces. Revolution isn’t another run-of-the-mill interface from big brother — it’s the interface the world has always asked for.

The best sound you’ve ever heard.

The most revolutionary thing to note about Revolution 2x2 is it’s sound quality: the sound of large, high-end converters that cost thousands of dollars is now available in a product that can fit in your hand — and not break the bank. Revolution uses our new “Macro-MMC” Clocking technology, which is based off of our numerous clocking products and modifications. Macro-MMC’s circuit implementation brings converters to new heights; well beyond what’s been seen in other recording interfaces. We also assembled our finest A/D//D/A technology, giving you the record-making power you’ve never had before in an interface this small, portable, and affordable.

Revolution also employs “PG-i” technology internally, based off of Black Lion Audio’s experience in engineering their “best-of-class” power conditioners.

All power rails are highly filtered in every active stage across Revolution 2x2 — something that isn’t even found in the most well-respected, high-end equipment. Power is decoupled across the entire circuit: the preamplifiers, the convertors, the internal power, and even the clock. This majorly helps reduce noise contamination from other equipment that is plugged into Revolution 2x2.

Top-tier, analog design.

Hi-fi digital design alone isn’t enough to cut it — it takes a serious analog circuit for the very best capture and playback. Revolution 2x2 is built with the most cutting edge, high-end ICs. High-end Vishay, Nichicon, and Wima capacitors are used throughout the entire circuit. All internal gain-staging has been optimized for the very lowest signal-to-noise ratio. All of the analog I/O has not only been built with the finest components, but are fully decoupled and balanced — right to the very core of the convertor! Most manufacturers do not follow this practice, and that allows extra noise contamination during both capture and playback.

Technical Specifications:

Mic Input

• Input Impedance: 3KΩ (balanced)
• Gain Range: 55dB
• Frequency Response: 20Hz – 20KHz +/- 0.25dB
• THD + N: .00098% (@12dB Gain)
• Dynamic Range: 116dB (A-Weighted)
• Crosstalk: < 100dB

Line Input

• Input Impedance: 14KΩ (balanced)
• Maximum Input: 20dBu
• Gain Range: 55dB
• Frequency Response: 20Hz – 20KHz +/- 0.25dB
• THD + N: .0022% (Min Gain)
• Dynamic Range: 126dB (A-Weighted)
• Crosstalk: < 100dB

Line Outputs

• Output Impedance: 95Ω (balanced)
• Max Output Level: 12dBu
• Frequency Response: 20Hz – 20KHz +/- 0.25dB
• THD+N .002%: (@ +10dBu)
• Dynamic Range: 106dB*

Instrument Input

• Input Impedance: 1MΩ (unbalanced)
• Gain Range: 55dB
• Frequency Response: 20Hz – 20KHz +/- 0.25dB
• THD + N: .00114% (@ 0dBu)
• Dynamic Range: 103dB (A-Weighted)
• Crosstalk: < 100dB

Headphone Outputs

• Output Impedance: 2.5Ω
• Maximum Signal Output: 9.3dBu
• Frequency Response: 20Hz – 20KHz +/- 0.5dB
