Ultra-portable and easy to use, the GT-1 delivers pro-level tones everywhere you play. Driven by the powerful BOSS GT-series engine, it gives you access to a huge selection of world-class amps and effects for all types of music. A streamlined interface enables quick and intuitive sound creation, while an assignable control switch and expression pedal provide dynamic real-time effects adjustment. And by connecting to , you can download free pro patches, editing software, and more. Equally suited for beginners, weekend warriors, and traveling players, the GT-1 packs premium sound in a compact and rugged package.
- Premium BOSS sound engine squeezed into a light and compact floor unit
- Modern design with no hard edges enables safe transport in a guitar bag
- Easy Select and Easy Edit functions for quickly choosing and tweaking patches
- Four AA batteries provide up to seven hours of playing time for busking and mobile gigs
- Onboard control switch and expression pedal; footswitch/expression pedal jack and USB
- Download ready-to-play pro patches for free at BOSS Tone Central
<iframe width="560" height="315" src="" frameborder="0" allow="accelerometer; autoplay; clipboard-write; encrypted-media; gyroscope; picture-in-picture" allowfullscreen></iframe>
SPECIFICATIONS
Sampling Frequency: 44.1 kHz
AD Conversion
- 24 bits + AF method
* AF method (Adaptive Focus method) is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.
DA Conversion: 24 bits
Effects: 108 types
Patches: 99 (User) + 99 (Preset)
Phrase Loop: 32 sec
Nominal Input Level: INPUT: -10 dBu, AUX IN: -20 dBu
Maximum Input Level: INPUT: +7 dBu, AUX IN: 0 dBu
Input Impedance: INPUT: 1 M ohm, AUX IN: 27 k ohms
Nominal Output Level: OUTPUT (L/MONO, R): -10 dBu, PHONES: -10 dBu
Output Impedance: OUTPUT (L/MONO, R): 1 k ohm, PHONES: 44 ohms
Recommended Load Impedance: OUTPUT (L/MONO, R): 10 k ohms or greater, PHONES: 44 ohms or greater
Controls
- DOWN switch, UP switch CTL1 switch
- EASY SELECT button, EASY EDIT button, FX1/COMP button, OD/DS button,
- PREAMP button, FX2/MOD button, DELAY button, REVERB button, MEMORY EDIT button, EXIT button, ENTER button, MENU button
1 knob, 2 knob, 3 knob
- Expression pedal
Display: Graphic LCD (132 x 32 dots, backlit LCD)
Connectors
- INPUT jack, OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
- CTL2, 3/EXP2 jack: 1/4-inch TRS phone type
- AUX IN jack: Stereo miniature phone type
- USB COMPUTER port: USB type B
- DC IN jack
Power Supply: Alkaline battery (AA, LR6) x 4, AC adaptor (sold separately)
Current Draw: 200 mA
Expected battery life under continuous use
- Alkaline: Approx. 7 hours
* These figures will vary depending on the actual conditions of use.
Accessories
- Owner's manual
- Leaflet "USING THE UNIT SAFELY"
- Alkaline battery (AA, LR6) x 4
Options (sold separately)
- AC adaptor: PSA series
- Footswitch: FS-5U, FS-5L, FS-6, FS-7
- Expression Pedal: FV-500L, FV-500H, Roland EV-5
SIZE AND WEIGHT
Width
- 305 mm
- 12-1/16 inches
Depth
- 152 mm
- 6 inches
Height
- 56 mm
- 2-1/4 inches
Maximum height
- 74 mm
- 2-15/16 inches
Weight (including battery)
- 1.3 kg
- 2 lbs 14 oz
