Bogen MT-250C - Black

250W Amp, was installed in a server rack for its life until 6/18.

POWER OUTPUT: 250 watts (rms), 40 - 14,000 Hz @ less than 1% distortion; 300 watts (rms), 50 - 12,000 Hz @ less than 2% distortion. PEAK POWER OUTPUT: 600 watts. POWER GAIN: 80 dB at 300 watts.

FREQUENCY RESPONSE: ±2 dB from 20 - 20.000 Hz.

REGULATION: Better than 2 dB from no load to full load.

SENSITIVITY: 250 mV for rated output.

NOISE LEVEL: -83 dB below rated output.

INPUT IMPEDANCE: Hi-Z, 50k; Lo-Z, 500/600 ohms with TL600 xfmr; Bridging, 10k ohms with TL10k xfmr.

OUTPUT CONNECTIONS: 25V, 45V, 70V and 120V balanced; 14V direct, unbalanced.

OUTPUT IMPEDANCES (Balanced and Unbalanced): 0.75, 1.0, 2, 2.5, 8, 16, 20, and 58 ohms.

AC POWER OUTPUT: 300 watts of 120-volt sine wave power for industrial applications at variable frequencies between 35 and 10,000 Hz, when driven from suitable input signal source.

CONTROLS AND INDICATORS: Front panelPower switch and power-on indicator. Rear panelSpeech filter switch (-5dB @ 100 Hz), input level control, and ac circuit breaker.

POWER REQUIREMENTS: 105-125 volts, 50/60 Hz ac; or dual 28 Vdc @ 8 amps. LINE CORD: Three-wire type SJ with three-prong grounded plug.

AUXILIARY RECEPTACLE: Three-wire grounded, 600 watts @ 120 volts. POWER CONSUMPTION: 105-125 Vac 50/60 Hz: 750W @full rated output, 75W @ idle. Dual(+ and -) 24 Vdc; 8A @ full rated output, 500 mA @ idle.

CIRCUIT PROTECTION: 10-amp breaker for ac line: electronic overload protection; thermostatic temperature protection.

TEMPERATURE RANGE: -20°C (-4°F) to +55°C (+130°F).

SEMICONDUCTORS: All-silicon, 27 transistors and 9 diodes.

DIMENSIONS: 17%" wide x 7½" high x 1134" deep.

RACK PANEL MOUNTING: RPK-36 accessory with 19" x 834" rack mounting adaptor panel.

FINISH: Low-lustre black.

WEIGHT: Shipping 55 lb., net 50 lb.
