Tube Mono Amplifier 2xEL34 PP / 35Wrms ReDesign PCB (Elektor) PCB
Our users rate Reverb
Power Tube Amp, with 2xEL34 PushPull in final stage. Input stage are pentode EF86.
The output power is around 35Wrms per channel. The schematic is shown in PDF file from
Elektor magazine. The PCB have easily breaking with a "guide" (to be a separate pcb, audio
channel, power supply, etc).
Input impedance : 1 MΩ
Input sensitivity : 600 mV
Impedance : 8 Ω (4 Ω optional)
Maximum Power : 39 W into 8 Ω
Bandwidth at 1 W : 5 Hz – >40 kHz THD+ noise (1 W/8 Ω, 1 kHz): 0.06% (B = 80 kHz)
Signal to noise : 62 dB (B = 22 kHz) 88 dB (A-weighted)
Supply voltage : Rail voltage - AC 320V / >400DC 300mA
Filament voltage : AC 6,3V > 7A (Stereo)
Board Dimension : 88mm x 174mm.
No components !!!.
Link for more info or manual (Inform me)
