Pioneer CT-97 Excellent condition!

=== PIONEER CT-97 ===

- Good working condition -

- Excellent aesthetic condition-

Type Stereo cassette player

Heads Recording: 1 solid ferrite head

Erasing: 1 ferrite head

Motor For constant speed drive: 1 electronically controlled DC motor with built-in generator.

For fast forward/rewind: 1 torque DC motor.

High winding speed Approximately 65 seconds (at C-60)

Uneven rotation (WRMS) Not more than 0.07%

Frequency characteristic General, LH band: 25 Hz ~ 16 kHz, 35 Hz ~ 13 kHz ± 3 dB

Chrome band: 20 Hz ~ 17 kHz, 30 Hz ~ 14 kHz ± 3 dB

S/N

Generic band, LH Dolby off: 52 dB or more

Dolby on: 62 dB or more (5 kHz or more)

When using chrome band: 4.5 dB improvement (over 5 kHz)

Distortion factor 1.7% or less (0 dB)

Operating part Solenoid operated, direct changeover type and preset for timer operation

Input sensitivity / Maximum allowable input

/ Microphone impedance: 0.22 mV/100 MV/30 k Ω (Compatible microphone impedance 600 Ω ~ 30 k Ω)

Line: 65 mV/100 k Ω

DINx1 (West German DIN standard)

Reference output level / maximum output level

/ Line impedance: 315mV/530MV/50k Ω

Headphone: 40mV/65MV/8 Ω

Semiconductor used Transistor: 71 (For electronic motor control: 3)

FET: 6

Diode: 75 pieces (For electronic motor control: 2 pieces)

Zener diode: 5 pieces

Light-emitting diode: 2

Power 100 V AC, 50 Hz/60 Hz

Power consumption Maximum 50W

External dimensions Width 420x Height 197x Depth 310 mm

Weight 12 kg

The device is serviced! It plays well and looks great!
