Djupviks Elektronik Gats [DE built]

Assembled by Djupviks Elektronik!

Grainy reverb into a WASP style filter with S&H

Djupviks Gats is a grainy reverb feeding into a wasp-style bandpass filter, with sample-and-hold modulation built into the signal path. By default, it samples your incoming audio to modulate the filter cutoff - creating stepped, glitchy textures that respond to your playing dynamics. The offset control lets you shape that response from aggressive ducking through to keeping the filter permanently cracked open.

Key Features
Signal Path: The input signal first hits a grainy reverb circuit before passing through a bandpass filter.
Sample and Hold (S&H): It features a built-in S&H circuit that can use your audio as a modulation source by default. This creates stepped, glitchy textures that react to playing dynamics.
Filter Modulation: A CV knob controls the amount of S&H modulation applied to the filter frequency.
Feedback Modes: A feedback switch allows you to choose between pre-filter and post-filter feedback, each offering distinct tonal "flavors".
Standalone Use: You can use the module as a standalone S&H source via its dedicated S&H output, bypassing the reverb and filter if desired.

Technical Specifications
Width: 12HP.
Filter Type: Modified WASP-style bandpass filter with frequency and resonance (Q) controls.
Reverb Control: Includes a switch for 100% wet or a 50/50 dry/wet blend.
Connectivity: Features a Gate input for external clocking and an S&H output
