Crazy Tube Circuits Orama Overdrive & Fuzz Pedal

Classic British Amp Power Meets Boutique Fuzz Mayhem

The Orama is a dual-drive pedal that combines the punch of a vintage British amp with the saturated voice of an early boutique fuzz.

Each side can be used independently or stacked, and a passive loop between the AMP and FUZZ sections lets you insert other pedals for expanded routing options.

Designed as a complete exploration of rock, stoner, and doom tones, it delivers everything from articulate crunch to earth-shaking sustain with a dynamic, expressive feel.

Amp Section: Orange-Inspired Drive

The AMP side uses a JFET circuit running at an internally boosted 34 V DC for authentic OR120-style headroom, punch, and harmonic complexity. It moves from edge-of-breakup to thick, saturated drive.

The F.A.T. and H.F.D. controls shape low mids and upper harmonics, making it easy to dial in anything from tight attack to roaring presence.

Fuzz Section: Boutique 90s Thunder

Inspired by the Frantone Peachfuzz, the FUZZ side delivers a thick, harmonically rich voice driven by power amplifier ICs.

Two voicings expand its range: RAW for a tighter, more dynamic feel, and BURN for heavier low end and massive sustain.

Designed for Creativity

Both sections stand on their own, yet stacking them unlocks towering, saturated tones ideal for rock, stoner, and doom.

The passive loop between sections allows modular gain staging that goes far beyond typical dual-drive pedals.

Crazy Tube Circuits Orama Features

• All analog dual pedal combining an amp circuit and boutique fuzz

• AMP side based on the Orange OR120, running at 34 V DC

• FUZZ side inspired by the Frantone Peachfuzz

• Two fuzz voicings: RAW (tight, dynamic) and BURN (heavy, saturated)

• AMP controls: Gain, F.A.T., Hz (bass), kHz (treble), H.F.D., Master

• FUZZ controls: Fuzz, Tone, Volume, RAW/BURN toggle

• Passive effects loop for creative routing

• Independent operation of both sections

• True bypass switching

• Power: 9V DC (82mA)

• Dimensions: 4.69" x 3.82" x 2.09"
