Micca OriGen G2 High Resolution USB DAC and Preamplifier 24 Bit/192 kHz PCM

The Micca OriGen G2 USB audio DAC and preamplifier is a studio master grade digital audio playback device that supports high resolution PCM audio up to 24-bit/192kHz. Its powerful preamp and headphone amplifier makes the OriGen G2 especially well suited in a compact desktop computer audio system together with powered monitors and headphones. Use the OriGen G2 to bypass a computer’s sound card and unlock the full sonic potential of your music library.

Digital Finesse

The digital circuitry of the OriGen G2 consists of a C-MEDIA CM6631A USB 2.0 High Speed 480Mbps audio controller and a Wolfson WM8740 stereo D/A converter. This capable combination provides asynchronous decoding and conversion of PCM audio up to 24-bit/192kHz. Advanced audio stream interface support includes both ASIO and WASAPI Push/Event output modes. Selectable USB or Optical S/PDIF digital input for flexible source connection.

Analog Brawn

The analog section of the OriGen G2 provides switchable line-level or headphone output, using JRC NJM4556 op amps with two output gain levels of 5.3Vrms and 1.6Vrms. The selectable gain design provides excellent drive capability into any downstream amplifiers with enhanced signal strength, low noise, and low interference. The headphone outputs are similarly powerful, with only 0.5 Ohm output impedance and able to drive 16-600 Ohm headphones.

Solid Construction

Starting with a steel tub chassis, the OriGen G2 is capped with an anodized aluminum top plate and finished with a solid machined aluminum volume knob. The TOCOS sealed potentiometer used for volume control offers long operating life and a smooth weighted feel. The all-metal construction makes the OriGen G2 exceptionally durable and helps shield against unwanted interference.

Inputs & Outputs

• Asynchronous USB 2.0 input for use with Windows XP/7/8/8.1/10, and MAC OSX.
• Optical S/PDIF input supports PCM signals from other audio sources.
• Front 3.5mm and 1/4” stereo headphone outputs. Powerful built-in headphone amp supports 16-600 Ω headphones.
• Rear 3.5mm stereo analog line level and combination optical S/PDIF digital output.

Digital Stream Formats

• PCM audio up to 24-bit/192kHz
• ASIO and WASAPI Push/Event support

Key Components

• C-MEDIA CM6631A USB 2.0 High Speed 480Mbps audio controller
• Wolfson WM8740 Stereo D/A Converter
• JRC NJM4556 operational amplifier

Ideal For:

• Use with the PB42X Powered Monitors for a high quality desktop computer audio system.
• Provide low noise and high power headphone output for enjoying music on any computer.
