TypeStereo  power amplifierOutputstereo:200W + 200W (Rated Output)
14.1 VRMS at 1 ohm Load
20.0 VRMS at 2 ohm Load
28.3 VRMS at 4 Ω load
40.0 VRMS at 8 Ω loadmono:400W (Rated Output)
14.1 VRMS at 0.5 Ω load
20.0 VRMS at 1 ohm Load
28.3 VRMS at 2 ohm Load
40.0 VRMS at 4 Ω loadOutput load impedanceStereo : 1 Ω, 2 Ω, 4 Ω, 8 Ω
Mono : 0.5 Ω, 1 Ω, 2 Ω, 4 ΩRated output band20 Hz to 20 kHzTotal harmonic distortion factor (when both channels are driven)0.1% or Less (Output 0.25W ~ 200W, 20 hz ~ 20 khz)Cross modulation distortion factor0.1% or Less (at Rated Output)Frequency response (at 1W output)20 Hz ~ 20 kHz + 0 -0.25 dB
10 Hz ~ 100 kHz + 0 -3.0 dBSignal-to-noise ratio95 dB or more (at rated output)Output voltage25VDamping factorstereo:16 (at 1 Ω load)
50 (at 2 Ω Load)
30 (at 4 Ω Load)
16 (at 8 Ω load)mono:16 (at 0.5 Ω Load)
50 (at 1 Ω Load)
30 (at 2 Ω Load)
16 (at 4 Ω Load)Input Sensitivity / Impedance0.75 V, 2.5V/100k ΩSemiconductor usedSilicon transistor : 49 units
Silicon Diode : 45 pcs
IC : 8Pwer120 V, 50Hz/60HzPower consumption70W (no signal)
550W (at maximum rated output)External dimensionsFront panel : 411.2 mm wide x 181 mm high
Body : Width 381x Height 166.7x Depth 368.3 mmWeight38.6kg
44.0 kg (when packed)
