Description:

This guitar speaker was developed to recapture the legendary sound of Celestion's 1970s 10s - a 10 speaker with a surprisingly meaty tone. Low in output but with the weighty low-end balance of a 12-inch speaker, the G10 Greenback features a complex mid-range and smooth vintage top-end. In small combos this speaker adds real class and when combined in a 4×10 gives rise to a raunchy full-bodied tone rich in low-end thump.

Specifications:

• Nominal diameter: 254mm / 10in
• Power rating: 30W
• Rated impedance: 8O or 16O
• Sensitivity: 95dB
• Chassis type: Pressed steel
• Magnet type: Ceramic
• Magnet weight: 0.56kg / 20oz
• Voice coil diameter: 1.75in / 44mm
• Voice coil material: Round copper
• Frequency range: 95-5500Hz
• Resonance frequency, Fs: 98Hz
• DC resistance, Re: 6.4O or 12.05O

Mounting Information:

• Cut-out diameter: 229mm / 9in
• Diameter: 254mm / 10in
• Magnet structure diameter: 124mm / 4.9in
• Mounting hole dimensions: 6.5x8.9mm / 0.25x0.35in
• Mounting hole PCD: 245mm / 9.6in
• Number of mounting holes: 8
• Chassis depth (inc gasket): 72mm / 2.83in
• Magnet depth: 30mm / 1.17in
• Overall depth: 102mm / 4.0in
• Unit weight: 1.6kg / 3.5lb
