Recommended for professional audio mid-bass applications in a small sealed cabinet.

• speaker_size: 10
• Basket Diameter in: 10
• Basket Diameter_mm: 254
• Nominal Impedance: 8
• Power Rating_Watts: 150
• Power Rating_Music Program: 300
• Resonance: 50
• Freq Range HZ: 57
• Freq Range kHZ: 4.5
• Sensitivity dB: 95.6
• Mag Wt_oz: 20
• Gap Height_in: 0.25
• Gap Height_mm: 6.4
• Voice Coil_Diam_in: 1.5
• Voice Coil Dia_mm: 38
• fs: 50
• Re: 5.31
• Le: 0.66
• Qms: 5.21
• Qes: 0.66
• Qts: 0.59
• Vas_ltr: 82.2
• Vas_cuft: 2.9
• VD: 114
• Cms: 0.46
• BL: 7.5
• Mms: 22
• EBP: 76
• Xmax: 3.2
• Sd: 355.4
• Xlim: 9.1
• Enc Recom Sealed: ACCEPTABLE
• Rec Enc Volume_Sealed Min_liters: 8.5
• Rec Enc Volume_Sealed Max_liters: 11.3
• Rec Enc Volume_Sealed Min_cuft: 0.3
• Rec Enc Volume_Sealed Max_cuft: 0.4
• Enc Recom Vented: ACCEPTABLE
• Rec Enc Volume_Vented Min_liters: 28.3
• Rec Enc Volume_Vented Max_liters: 53.8
• Rec Enc Volume_Vented Min_cuft: 1
• Rec Enc Volume_Vented Max_cuft: 1.9
• Drive Volume Displaced_liters: 0.95
• Driver Volume Displaced_cuft: 0.034
• Overall_Diam_in: 10.11
• Overall_Diam_mm: 256.8
• Baffle Hole_Diam_in: 9.13
• Baffle Hole_Diam_mm: 231.9
• Front Seal Gask: Yes
• Rear Seal Gask: Yes
• Mounting Holes_Diam_in: 0.23
• Mounting Holes_Diam_mm: 5.8
• Mounting Holes_BCD_in: 9.6
• Mounting Holes_BCD_mm: 243.8
• Depth_in: 3.9
• Depth_mm: 99.1
• Net Weight_lbs: 4.5
• Net Weight_kg: 2.04
• Ship Weight_lbs: 5.6
• Ship Weight_kg: 2.54
• Coil Construction: Copper voice coil
• Coil Former: Polyimide former
• Magnet Comp: Ferrite magnet
• Core Details: Vented and extended core
• Basket Material: Pressed steel basket
• Cone Composition: Paper cone
• Cone Edge Composition: Cloth cone edge
• Dust Cap Composition: Solid composition paper dust cap
• coloration:
• Genre:
• Model Group: American Standard
• Subwoofer Usage:
• Woofer Usage: Yes
• MidBass Usage: Yes
• Midrange Usage: Yes
• Bass Guitar: Yes
• Closed box: Yes
• Reflex Box: Yes
• Scoop Loading:
• Horn Loading: Yes
