Allen & Heath CQ-12T Ultra-Compact 12in / 8out Digital Mixer

The CQ-12T is the smallest mixer in the CQ range, making it perfect for various applications such as home recording, streaming, band rehearsals, small gigs, and speeches. It offers versatile mixing styles with Quick Channels for easy, one-knob instrument-specific processing or Complete Channels for advanced parameter tweaking. The Gain Assistant simplifies setting optimal gain levels and continuously monitors levels during performances to prevent unexpected peaks. The Feedback Assistant automatically detects and eliminates feedback using up to 16 filters per output. CQ delivers pristine 96kHz audio quality with studio-grade processing and a range of FX options. It introduces user-friendly reverb, delay, and modulation algorithms with instrument-specific presets and offers tactile control via a 7" touchscreen, rotary control, and Custom SoftKeys, along with remote control capabilities through the CQ MixPad app.

Features:

• Inputs
  5 XLR
  5 XLR/TRS Combi
  2 TRS (stereo)
• Outputs
  2 XLR (Main)
  6 TRS (Monitors)
• Stereo USB record/playback with dedicated input channel
• Stereo Bluetooth playback with dedicated input channel
• 16×16 USB-B interface (48/96kHz)
• 16×16 SD record/playback (48/96kHz)
• 2 FX engines
• 3 Custom SoftKeys
• Dual Footswitch connection
• 7” Capacitive touchscreen with associated rotary control
• Assignable TRS headphone output

Specifications:

• Input Channels: 12
• Output Channels: 8
• Digital Conversion: 24-bit/96kHz
• Touchscreen: High-resolution touchscreen interface for intuitive control.
• Network Connectivity: Dante audio networking for seamless integration.
• Effects: Built-in effects include reverb, delay, chorus, and more.
• Wi-Fi Control: Wireless control via tablet or smartphone for ultimate flexibility.
• Rack-Mountable: Optional rack-mount kit available for easy installation in a standard rack.
