The D20 is the world’s first Two-notes Torpedo-Embedded amplifier. This all-tube head has an optional reactive load for organic feel and tone when playing without a cab and hosts virtual cabinets onboard for direct recording, silent playing, and live performance without a microphone. We set out to build an amp that not only has this new modern feature set but sounds incredible on its own as a standalone amplifier. The result is something convenient and great sounding at the lowest price point REVV has ever had.

Product Features

• Versatile 20/4W tube guitar amp head
• Features advanced Two-notes cabinet-emulation technology
• 6 customizable virtual cabinets (expandable to 128 via MIDI)
• Option to use simulated power section
• Automatically engages reactive load for amp protection
• 3-band EQ, Volume, and Gain controls for easy tone adjustments
• Push-pull gain pot for crunchier tones
• Power-reduction circuit for authentic sounds at lower volumes
• Buffered series FX loop for pedal integration
• Switchable 4-/8-ohm speaker jack for cabinet compatibility
• Easy bias test and fuse access

Attributes

• Color: White
• Power Tube: 6V6
• Total Power: 20W to 49W

Technical Specifications

• Type: Tube
• Features: Effects Loop
• Amp Type: Amp Head
• # of Channels: 1
• Wattage: 20W
• Dimensions: 7.5" H x 12.31" W x 6.31" D
• Weight: 9 lbs
• Power Tubes: 2 x 6V6
• Preamp Tubes: 2 x 12AX7
• EQ: 3-Band EQ
• Inputs: 1 x 1/4"
• Outputs: 1/4", XLR (Torpedo Out)
• MIDI: In, USB
• Power Source: Standard IEC AC cable
• USB: 1 x Type B
• Construction Material: Aluminum Enclosure
• Impedance: 4 ohms
• Mono/Stereo: Mono
