The X-V 6418 tube microphone kit is designed for easy assembly, and natively supports X-R series capsules (male RCA output, or female RCA output with male-male RCA adaptor or remote cable), or may be adapted to support many other electret capsule microphones.
Please refer to the X-V kit weblog post on the Naiant website for schematic and details on assembly.
This kit includes a case, microphone clip, PCB mounted to XLR pins, and all components including one 6418 tube--not tested, new old stock, for this deluxe kit only!
The deluxe kit also includes the X-R side address cardioid capsule, windscreen, and RCA male-male adaptor.
side-address cardioid capsule specifications:
Maximum Level, 1kHz @ 1% THD: 132dBSPL
Sensitivity, 1kHz @ 94dBSPL: -34dBV/Pa, +/-2dB
Frequency Response @ 1m (-3dB): 80Hz to 20kHz
Polar Response, 90°: -5dB @ 1kHz
Polar Response, 180°: -13dB @ 1kHz
Self-Noise: 16dBA
Weight: 23g (0.8oz)
Dimensions: 32mm x 19mmø (1 1/4″ x 3/4″ø)
