A superb gateway into the time-honored Fender family, the Squier Affinity Series Telecaster delivers legendary design and quintessential tone for today’s aspiring guitar hero.

This Tele features several player-friendly refinements such as a thin and lightweight body, a slim and comfortable “C”-shaped neck profile, a string-through-body bridge for optimal body resonance and sealed die-cast tuning machines with split shafts for smooth, accurate tuning and easy restringing. Loaded with dual Squier single-coil Tele pickups with 3-way switching for genre-defying sonic variety, this model is ready to accompany any player at any stage.

STRING-THROUGH-BODY TELECASTER BRIDGE
A string-through-body bridge improves resonance through the body and increases string tension for a rock-solid feel.

SQUIER SINGLE-COIL TELECASTER PICKUPS
Voiced in-house at Fender, these Squier single-coil pickups produce crisp, articulate tone for a wide variety of styles.

SEALED DIE-CAST TUNING MACHINES WITH SPLIT SHAFTS
Sealed die-cast tuning machines have a smooth action for accurate tuning, and the split shafts make changing strings a breeze.

• Thin and lightweight body
• String-through-body bridge
• Slim and comfortable “C”-shaped neck profile
• Two Squier single-coil pickups
• Sealed die-cast tuning machines with split shafts

General

Series:  Affinity Series®
Orientation: Right-Hand
Color:  Lake Placid Blue
Country Of Origin:  CN

Neck

Neck Material:  Maple
Neck Finish:  Satin Urethane with Gloss Urethane Headstock Face
Neck Shape:  "C" Shape
Neck Construction:  Bolt-On
Fingerboard Radius:  9.5" (241 mm)
Fingerboard Material:  Indian Laurel
Position Inlays:  Pearloid Dot
Side Dots:  White
Number of Frets:  21
Truss Rod:  Head Adjust
String Nut:  Synthetic Bone
Nut Width:  1.650" (42 mm)
Nut Material:  Synthetic Bone
Fret Size:  Medium Jumbo
Scale Length:  25.5" (648 mm)

Body

Body:  Poplar
Body Finish:  Gloss Polyurethane
Body Shape:  Telecaster®
Body Material:  Poplar

Hardware

Bridge:  6-Saddle Strings-Through-Body Tele®
Pickguard:  3-Ply White
Pickup Covers:  Neck: Chrome; Bridge: Black
Control Knobs:  Knurled Flat-Top
Switch Tip:  Black
Hardware Finish:  Chrome
Tuning Machines:  Sealed Die-Cast with Split Shafts
String Trees:  Dual-Wing
Strings:  Nickel Plated Steel (.009-.042 Gauges)
Neck Plate:  4-Bolt Squier®
Strap Buttons:  Standard

Electronics

Bridge Pickup:  Ceramic Single-Coil
Neck Pickup:  Ceramic Single-Coil
Pickup Configuration:  SS
Controls:  Master Volume, Master Tone
Switching:  3-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup

Measurements

Shipping Dimensions:  4.00x15.00x44.00 IN
Shipping Weight:  12.50 LB
Shipping Length:  44.00 IN
Shipping Height:  4.00 IN
Shipping Width:  15.00 IN
