Tremoline FT36-R3-SP Stainless Steel double locking tremolo + R3 (42.8mm) Locking Nut, low profile

Price$309.99
+ $33.72 Shipping
10+ in stock
This seller is open to offers

14-Day Return Policy

Enjoy peace of mind with your new gear

Shop Policies
Shipped From
Tremoline
Sofia, Bulgaria
Joined Reverb
2022

Reverb Protection

Simple Returns, Secure Transactions, Human Support

Learn more

Secure Checkout

The Tremoline FT36 is unique and presents the only Flat Top Fine Tuning Double Locking Tremolo system, a new original tremolo system, patented in the USA, Germany and other countries.
A Few Benefits of this original product:
CONVENIENCE - the solution of sinking fine tuning screws into the saddle bodies and multilayer construction, allowing very comfortable guitar playing without any fear that the strings will go out of tune.
UNIVERSALITY – Tremoline FT36 retrofits the most wide spread Double locking tremolos and their similar copies.
QUALITY – The use of a thicker sustain block and hard, non-magnetic STAINLESS STEEL, leads to increased sustain and sound quality.
ENDURANCE - The use of specially selected STAINLESS STEEL for all metal parts, gives not only durability, but also leads to keeping a good looking appearance for years.

The Tremoline FT36-R3-SP is equipped with R3 (width-42.8mm) solid stainless steel locking nut.
Two fixing options for Locking nuts - from above (by two wood screws) and from underneath (by two metric thread screws).
The Tremoline FT36 is equipped with a Adjustment screw allowing very precise Intonation adjustment without any need of using of additional intonation tool.
The Tremoline FT36 is the only tremolo systems that allows the guitar pick usage for adjustment and makes fine tuning process so simple, quick and intuitive.
All fine tuning springs are hidden mounted into the saddle bodies.
The tremolo arm spring is hidden mounted into the Sustain Block in order to avoid the backlash of the tremolo arm.
All metal parts are produced only from solid bars, sheets and wires of specially selected STAINLESS STEEL alloys through variety of cold machining processes.
All parts are NON-MAGNETIC, which leads to the lack of magnetic interference (unwanted noise).
The only plastic part is made of specially selected engineering plastics, which withstand heavy loads, is acid-resistant, dimensional stable, long lasting and provide low friction.
The use of a thicker solid STAINLESS STEEL sustain block (12mm) instead of a chip die-casting 8mm thick standard sustain block leads to a lack of purchasing the additional fat brass sustain block and to increasing of the sustain.
All parts comply with RoHS 2 (European Directive 2011/65/EU for the Restriction of use of certain Hazardous Substances).
All parts are NON-ALLERGENIC and comply with ISO 10993-10 (European standard for biocompatibility).
The Tremoline FT36-R3-SP (with its low and flat top profile) is the right solution for guitar players who love and often use both Guitar Techniques - Vibrato and Palm Muting.
For more information (pdf, photos, videos, specs, manuals and etc.) visit .
Made in EU.

TECHNICAL DATA
Tremolo Unite type:   double locking
E-E Center width:   52.0mm / 2.06"
String spacing:     10.4mm / 0.41"
Pivot Stud spacing:   74.2mm / 2.92"
Tremolo Unit radius:   405.4mm / 16.0"
Sustain Block thickness: 12.0mm / 0.4724"
Sustain Block Height:   33.0mm / 1.30"

Locking Nut type:   R3
Orientation:     Right handed
Nut Base width:     42.8mm / 1.6875"
E-E center width:   36.0mm / 1.4155"
String spacing:     6.6mm / 0.2591"
Locking Nut radius:   304.8mm / 12.0"
Nut Base fixing:   from above - underneath
Retainer Bar kit:   included

SPECIFICATION
Tremoline FT36 tremolo system set includes following parts:

Tremolo Unit set:   1
  Baseplate   1
  Sustain Block   1
  Retainer Bar   1
  Saddle Assembly   6
  String Lock Insert 6
  Fine Tuning Screw 6
  Saddle Mounting Screw 6
  String Lock Screw 6
  Trem Mounting Screw 2
  Retaimer Screw   2
  Shim Ring   12
  Tremolo Arm Spring 1
  Tremolo Arm Sleeve 1
  Tremolo Arm Screw 1
Spring Claw:     1
Adjustment Screw:   1
Pivot Stud:     2
Pvot Insert:     2
Tremolo Arm:     1
Tremolo Spring:     4
Spring Claw Screw:   2
Clamp Cable Lug:   1
Cable Lug Screw:   1
Key wrench 1.5mm:   1
Key wrench 2.5mm:   1
Key wrench 3.0mm:   1
Retainer Plate:     1
12mm Retainer Screw:   2
Locking Nut Set:   1
  Locking Nut Base 1
  Locking Nut Clamp 3
  Locking Nut Washer 0
  Clamp Screw   3
  Nut Mounting Screw 2
Nut Mounting Bolt   2
Nut Mounting Washer   2
Nut Bar       1
Nut Bar Screw     2
User Manual     1
