Nordvang Custom Gravity V2.5

Brand New / Neuve.
2 years warranty / 2 ans de garantie.

We ship same day if you order before 04:00pm local time.
24-48h Delivery depending of your country, FREE Express shipping to France and Europe.
We ship worldwide. No VAT for buyers outside EU, please enter your location in the Reverb system to get the excluding taxes price.

=====================

**The Gravity v2.5 update**
- Update to the version 2.5: TS side

- we have added an additional clipping diode option, so besides the 2-diode symmetrical (stock), 3-diode asymmetrical you now also have a 4-diode symmetrical clipping option. By popular demand the Gravity v2.5 now features a TRS split function to use with pedal looper systems like the GigRig etc. The TRS split is enabled via three internal dip switches.

To make room for the dip switches for the TRS split functionality, we have at the same time reduced the number of switching options for tweaking of the TS side (side A) compared to the v1. Side A now features a stock and an alternate setting for each of the three parameters: clipping, clarity and brightness.
The enclosures are now finished in a fine texture powder coat.
Gravity is our take on two all-time favorite overdrive circuits, the K-style circuit and a TS10 circuit all in one enclosure! A new dual overdrive specializing in mid push, Gravity will give you the ability to cut through the mix in any situation.

Our inspiration for this pedal lies in its name, Gravity and also by the later live lead tones of John Mayer. In particular the outro solo tone in his song "Gravity", and intro in his song "Belief", where he stacks these two pedals to obtain that signature tone with a thick wall of mids. The TS10 is often used as the main lead tone and the K-overdrive is added as a second cascading gain stage, either as a pre drive into the TS10, or as a post drive.

We have recreated the circuits in each pedal staying true to the original, but added switching options for additional tone shaping. We have kept both buffers that were used in the original designs in order to replicate the exact interaction between the two circuits. The Gravity overdrive is divided into a side A (left) and a side B (right), separated by the order toggle switch in the middle which is used to flip the internal order of the effects and hence the signal path from guitar to amp.

Side A features the TS10 circuit with external knobs for DRIVE, TONE, LEVEL and a three position toggle switch labeled LOWS. The lows switch changes the bass response of the circuit. Internally you find three dip switches (clipping, clarity and brightness) that further enables you to tweak your tone.

The side B features the K-circuit with external knobs for GAIN, TREBLE, OUTPUT and a two position toggle switch labeled CLIPPING. The clipping switch toggles between a pair of germanium or schottky clipping diodes.

Both sides can be used separately or stacked.

TRS split: Besides using the two sides of Gravity in serial mode, either A->B or A<-B, the Gravity V2 can split side A & B into separate effects. The two 1/4" jacks, which in serial mode are used for signal in and out, will in split mode serve as IN+OUT for each side.

That is done via a - TRS to 2 x TS - 1/4 " jack cable.

The right side "IN" jack is IN+OUT for side B. (TIP = in, RING = out)

The left side "OUT" jack is IN+OUT for side A. (TIP = out, RING = in)

PLEASE NOTE THAT THE EXTERNAL ORDER TOGGLE SWITCH MUST BE IN UP POSITION A <- B

- We have added a dip switch for boosting the output of the TS side.
