The Blackmagic Design UltraStudio 4K Thunderbolt 2 is an external 1RU/table-top I/O device with two 20Gb/s Thunderbolt ports. It captures DCI 4K 4:2:2 or UHD 4K YUV 4:2:2 by single-link 6G-SDI up to 30p and by dual-link 6G-SDI from 50p to 60p; 1080p RGB 4:4:4 by single-link 3G-SDI; 1080p 4:2:2 by single-link HD-SDI; 1080p 4:4:4 by dual-link HD-SDI; and DCI/UHD 4K 4:2:2 by HDMI. 4K can be input/output compressed and uncompressed. The SDI inputs also support dual-channel 2D/3D stereoscopic workflows. UltraStudio 4K is capable of hardware-based HD down/up/cross conversion.
The other connections are Component and Composite on BNC, 2-channel analog audio on XLR, 2-channel AES/EBU audio on BNC, timecode input and output on XLR, Blackburst and Tri-Sync, and RS-422 deck control. A color LCD and six quick-access video and audio input buttons are built in on the front panel.
4K, 1080p, 3D Input &
Output
DCI 4K 4:2:2 or UHD 4K YUV 4:2:2 by single-link 6G-SDI
DCI 4K 4:2:2 by HDMI
1080p RGB 4:4:4 by single-link 3G-SDI
1080p 4:2:2 by single-link HD-SDI
1080p 4:4:4 by dual-link HD-SDI
Dual-channel 2D/3D stereoscopic by SDI
4K Compressed or Uncompressed
UltraStudio 4K Thunderbolt 2 supports popular compressed video formats such as
ProRes and DNxHD as well as 10-bit uncompressed video. When working with
uncompressed video all captured images are a perfect pixel-for-pixel clone of
the source without any quality loss. Get the sharpest keying with green
screens, cleanest compositions, superior color correction, and more.
Work in 10-Bit 4:4:4
UltraStudio 4K Thunderbolt 2 features built-in 6G-SDI connections that operate
at four times the speed of regular HD-SDI, meaning you can capture Ultra HD and
4K with only one BNC cable instead of four. This high bandwidth connection is
perfect for full color resolution 4:4:4 video, which is great for video effects
and high frame rate video up to 1080p60. UltraStudio 4K Thunderbolt 2 also
supports dual stream 3D with capture and playback of two independent channels.
Supported Codecs
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50,
DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, Apple ProRes 4444, Apple
ProRes 422 (HQ), Apple ProRes 422, Apple ProRes (LT), Apple ProRes 422 (Proxy),
Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, and Uncompressed 10-bit
4:4:4.
Supported Applications
Apple Final Cut Pro X, Adobe Premiere Pro, Avid Media Composer, Adobe After
Effects, Nuke - The Foundry, DaVinci Resolve, Avid Pro Tools, Steinberg Cubase,
Steinberg Nuendo, Adobe Photoshop, Avid Symphony, Avid News Cutter, Tools On
Air just:in / live:cut / just:play / just:live, Softron OnTheAir Video/
MovieRecorder / OnTheAir CG, Flash Media Encoder, Wirecast, Livestream
Procaster, Resolume Avenue 4, Sony Vegas Pro, Corel VideoStudio Pro X4, CyberLink
Power Director, MAGIX Video Pro X4, Vidcaster Pro / Studio / Broadcast,
Uniplay, Playbox AirBox, CasparCG, Magicsoft CG, Xsplit Broadcaster, and Harris
Infocaster
