Mamba 8 Combo to DB25 and 8 Combo to 8 Male 1RU XDB-XLR Patch Bay

Mamba - 8 XBD + 8 XLR 1RU Patch bay - Special clearance Sale

The 8 ch Analog to DB25s PLUS 8 channel XLR to XLR is a half & half of Mamba 16XDB and Mamba 16XLR patch bay models in an 1RU. This new addition allows customers to connect 8 ch using DB25 and 8 ch via XLR cable. The left side is 8 channels of Combo [XLR, TRS or TS] to DB25. Pls contact for other options such as XLR F as input to DB25 (Tascam Analog), XLR M (combo - TRS) as output, 4x4AES inxout, 8 ch Passive Split to 2DB25s. The XLR to XLR side (right) has options for Combo to Male, Male to Combo, F to M, M to F, Combo to Combo and other custom config. The parts, design using PCBs and construction are carefully done to provide the best audio quality and sleek finish. You can also check out 32XLR to 4 DB25 or XLR to XLR or ULN-8 or LIO-8 or AES/EBU patch bays. You can also check out or or or or patch bays.

This Model # 8CDB_8C2M - 8 Combo to DB25 & 8 Combo to XLR Male.

We have many other options like 8FDB_8C8M or 8FDB_8M8F or 8FDB_8M8F or 8CDB_8M8C or AES +XLR etc etc, pls contact us

Specifications:

Rack Mountable 1RU - 2" depth only

Nuetrik Genuine gold plated connectors

XLR Combo - XLR, TRS, TS - Mic, Line level or Instrument input

XLR F - XLR mic input or AES input

XLR Male - Nuetrik Gold Plated

DB25 - Analog Tascam or Passive split 2 DB25s Analog Tascam

DB25 - 1 Tascam AES and 1 Yamaha AES (AES option)

XLR to DB25 side Options - Combo or XLR F - input - XLR Male as output, AES 121 or AES TxR, Passive Input (combo) Split to 2 Db25

XLR to XLR Side Options - 8 Combo to 8 Male, 8 Male to 8 Combo, 8 XLR F to 8 M, 8 XLR M to 8 XLR F, 8 Combo to combo & all other custom config.

PCB mounted and clean signal pass thru

Phantom Power pass thru OK

Solid steel and sleek finish

5 year warranty
