Analog Physical Modeling Engine with multiple synthesis and oscillator types Onboard effects processor with five types add depth to your sound The effect types are: OFF (effect bypass,) Delay, VCM Phaser, VCM Chorus/Flanger and Distortion 8-note polyphony Allows complex chords and pads or switch to mono Mode for fat synth bass or solo leads. Keyboard Based on the FS action found on the flagship Motif XF, HQ (High Quality) Mini Keys provide premium feel and response for fast, accurate and natural playing. Looper Integrated Phrase Looper: capture song ideas or just jam Pedal Continuous controller pedal input for volume control Speakers 2W 3cm stereo speaker system lets you play any place, any time Specially designed bass reflex port technology enhances bass response for full, rich sound Battery powered Uses six "AA" batteries with five hours of life USB USB "TO HOST" allows MIDI connectivity to your USB-equipped computer or iOS device Audio output Dual 1/4"unbalanced line outputs provide connection to mixers, audio interfaces, DI boxes and more Audio input A 3.5mm aux line input lets you connect and hear mobile devices, tablets and more through the instrument Soundmondo is a free sound sharing community that lets you discover, create and share reface Voices and Set Lists using Google Chrome any place, any time you're online. Powered by Web MIDI, Soundmondo is simple to use - just connect reface to Chrome and you're ready to create or start browsing.

• Amplifiers 2 W x 2
• Speakers 3 cm x 2
• Power Supply
• Power Consumption 6 W (When using PA-130 power adaptor)
• Battery Life Approximately 5 hours
• Auto Power Off Yes
• Power Supply Adaptors PA-130 or an equivalent recommended by Yamaha
• Batteries Six "AA" size batteries or Ni-MH rechargeable batteries
• Included AC adaptor*, MIDI breakout cable, Owner's Manual, Warranty* *May be included depending on your locale
• Number of types 5 OSC types
• Effects Distortion, VCM Chorus/Flanger, VCM Phaser, Delay
• Dimensions Width 530 mm (20 7/8")
• Height 60 mm (2 3/8")
• Depth 175 mm (6 7/8")
• Weight 1.9 kg (4 lbs, 3 oz) (not including batteries)
• Number of Keys 37 keys
• Type HQ mini (High-Quality mini)
• Initial Touch Yes
• Maximum Polyphony 8
• Engine AN (Analog Physical Modeling)
• Phrase Looper Yes
• DC IN DC IN (12 V) jack
• Headphones PHONES (6.3 mm, stereo phone jack)
• MIDI MIDI (mini-DIN IN/OUT)
• AUX IN AUX IN (3.5 mm, mini stereo phone jack)
• OUT PUT L/MONO, R (6.3 mm, TS phone jack, unbalanced)
• USB TO HOST USB (TO HOST)
• Pedal Type FOOT CONTROLLER: FC7 (optional) (to adjust the volume)

  MPN: reface CS
