Origin Series 20 Watt 1 x 10" Vacuum Tube Combo

ORIGIN

Expression begins with the all valve Origin series. It delivers two inbuilt voices, a new tilt control, Powerstem Marshall's new power reduction technology and forms the perfect marriage with FX pedals. The classically styled single channel amps generate rich and harmonic tones that are ideal for players to explore new possibilities and craft their sound. There is a 2-way footswitch available with all models so you can control the gain boost and turn the FX loop on and off. The series has something for those playing in the bedroom, at rehearsal or on the stage.

ORIGIN20C

This 20w combo is designed for those that like expression through innovation. Using a Celestion V type speaker the Origin20C provides a classic all-valve Marshall tone. A 2-way footswitch allows you to control the gain boost and turn the FX loop on and off. With classic styling and modern features this amp generates rich, harmonic tones so that you can craft a sound to suit your personality.

Features:

GENERAL

• Model: Origin20C
Range: Origin
Technology: Valve
Channels: 1

ELECTRONICS

Output wattage: 20w
Outputs: Speaker outputs: 3 x 1/4" jack sockets (16 ohm load / 8 ohm load), DI out (1/4" jack)
Inputs: 1 x 1/4" jack instrument input, footswitch
Controls: Gain, boost, tilt, bass, middle, treble, master, presence, power scaling
Effects: None
Effects loop: Yes, Send/Return

SPEAKERS

Speaker configuration: 1x10"
Speaker model: Celestion V type (16 ohm, 30W)
Unit impedance: 16 ohm

VALVES

Preamp valves: 3 x ECC83
Power amp valves: 2 x EL34

ACCESSORIES

Footswitch: PEDL-90016 included
Cable: Detachable power cable included

DIMENSIONS

Weight: 30.6lbs (13.9kg)
Width: 20.4” (520mm)
Height: 16.5” (420mm)
Depth: 9.4” (240mm)
