This is a handmade guitar by SurfdestoryR, rich in tonal possibilities. Unfortunately doesn't get as much playing time as it deserves, so time to pass it on to a new home. Sound is great and highly customizable, includes A5 magnets to swap to taste. In original condition as received.
From original Listing:
Lefty 25.5" scale length offset guitar
Total guitar weight is approximately 9lbs
BODY:
1.5" slab thickness
Mahogany (center) with Fir (upper side), Walnut (lower side) woods
Forearm/Tummy contours
Finished in Purple with Magenta stripes; Acrylic clear coat
NECK:
Maple neck with rosewood fretboard
Block inlays
14" radius
Thin "C" Profile
Matching Headstock, Back of neck colored transparent black, Finished in light Satin clearcoat for fast feel
Jumbo frets (leveled & crowned)
Vintage style Kluson tuners
3 roller string trees installed close proximity to nut
Six bolt mounting
Strong back angle from body/neck pocket
PICKGUARD:
Clear acrylic with Black/Grey chevron underlay
Internal side fully shielded
PICKUPS:
Neck - 7.6k P90 w/ Mosrite style pan pole screws; 80x13mm A5 bar magnet (neck side) + 63x10mm A5 bar magnet (middle side)
Bridge - 9.4k (top) + 7.4k (bottom - RW) stacked pair of P90s w/ Mosrite style pan pole screws;80x13mm A5 bar magnet (bridge side) + 63x10mm A5 bar magnet (middle side)
Neck Pickup is RWRP with top/main bridge coil
ELECTRONICS: (Left to Right)
3-way Toggle - Pickup Select (N/N+B/B)
3-way Slider - Neck PU EQ: Strangle (.001cap)/Bypass/Rhytmn (.047cap at 47k)
3-way Slider - Bridge PU EQ: Strangle (.001cap)/Bypass/Rhytmn (.047cap at 47k)
500k Volume - Neck
1meg Volume - Bridge
2-way Mini Toggle - Phase reversal switch (Neck PU)
3-way Mini Toggle - Bridge PU coils (series/split/parallel)
Output Jack
HARDWARE:
JM/Jag saddle unit with Standard saddles (Low E/A/D) + Graphtec string savers (G/B/High E)
Saddle unit mounted atop metal shims for full surface contact + break angle function
Mustang Vibrato unit with modified Jazzmaster Arm
Ships in wooden crate built as a case
This is not a Fender nor intended as a clone of one. This is a rugged DIY build: ALL BELMISHES ARE INTENTIONAL - Don't like it don't buy it!
