The Blackface era sibling of the P15N is a powerful, open sounding speaker with a cutting presence on the full range of frequencies. The C15N is very efficient and delivers dynamic, high-headroom and punchy tone from bass to trebles. It is the first-choice speaker for many pedal steel and blues players. It is very commonly found in Pro® and Vibrolux® amps in the ‘60s and is used in the low frequency drum of the Leslie® 122 and 147 amplifiers.

Guitarist Description: Tight low-end and clear, bright highs. Responds to overdrive distortion with a gritty edge.

• Lows: Fat
• Mids: Aggressive
• Highs: Bright
• Overdrive: Smooth

Product Measurements

Diameter: 15 in.
Voice Coil Diameter: 1.5 in.
Depth: 5.807 in.
Outer Diameter: 15.0787 in.
Inner Diameter: 14.0945 in.
Mounting Hole Bolt Circle Diameter: 14.6457 in.
Magnet Assembly Diameter: 5.2755 in.
Magnet Assembly Depth: 1.1811 in.
Mounting Hole Diameter: 0.2362 in.
Nominal Overall Diameter: 385.00 mm
Nominal Voice Coil Diameter: 38.00 mm
Flux Density: 1.00 T
Voice Coil Winding Depth: 10.00 mm
Magnetic Gap Depth: 8.00 mm
Magnet Type: Ferrite
Voice Coil Winding Type: Copper
Voice Coil Former: Kapton
Cone Material: Paper
Surround Material: Integrated Paper
Dust Dome Material: Solid Paper
Basket Material: Pressed Sheet Steel
Surround Treatment: Yes
Voice Coil DC Resistance (Re): 6.20 Ω
Resonance Frequency (ƒS): 73.00 Hz
Mechanical Q Factor (QMS): 6.80
Total Q Factor (QTS): 1.11
Mechanical Moving Mass (MMS): 54.70 g
Mechanical Compliance (CMS): 87.00 µm/N
Force Factor (BxL): 10.85 Wb/m
Equivalent Acoustic Volume (VAS): 70.30 liters
Linear Displacement, maximum (XMAX): 1.00 mm
Reference Efficiency (nO): 2.84 %
Diaphragm Area (SD): 754.80 cm2
Losses Electrical Resistance (RES): 39.00 Ω
Voice Coil Inductance @ 1 kHZ (LE): 0.93 mH
Rated Power: 50.00 W
Musical Power: 100.00 W
Sensitivity @ 1W, 1m: 96.30 dB
