The C15K is the contemporary version of the C15N and offers one of the fullest sounding tones in the entire range. With powerful basses, rich in the whole midrange and smooth but extended in the treble range, the C15K is a first choice for traditional jazz players, as well as for fusion and roots rock styles.

Guitarist Description: Full, boomy low-end with aggressive mids and bright highs. Responds to overdrive distortion with a strong rhythm crunch and fuzz lead voice

• Lows: Fat
• Mids: Aggressive
• Highs: Bright
• Overdrive: Crunchy

Product Measurements

Diameter: 15 in.
Voice Coil Diameter: 2 in.
Depth: 6.0826 in.
Outer Diameter: 15.0787 in.
Inner Diameter: 14.0945 in.
Mounting Hole Bolt Circle Diameter: 14.6457 in.
Magnet Assembly Diameter: 6.0629 in.
Magnet Assembly Depth: 1.4566 in.
Mounting Hole Diameter: 0.2362 in.
Nominal Overall Diameter: 385.00 mm
Nominal Voice Coil Diameter: 50.00 mm
Flux Density: 1.15 T
Voice Coil Winding Depth: 10.00 mm
Magnetic Gap Depth: 8.00 mm
Magnet Type: Ferrite
Voice Coil Winding Type: Copper
Voice Coil Former: Kapton
Cone Material: Paper
Surround Material: Integrated Paper
Dust Dome Material: Non-treated Cloth
Basket Material: Pressed Sheet Steel
Surround Treatment: Yes
Voice Coil DC Resistance (Re): 6.85 Ω
Resonance Frequency (ƒS): 71.00 Hz
Mechanical Q Factor (QMS): 10.40
Total Q Factor (QTS): 0.75
Mechanical Moving Mass (MMS): 53.50 g
Mechanical Compliance (CMS): 94.00 µm/N
Force Factor (BxL): 14.19 Wb/m
Equivalent Acoustic Volume (VAS): 75.80 liters
Linear Displacement, maximum (XMAX): 1.00 mm
Reference Efficiency (nO): 3.60 %
Diaphragm Area (SD): 754.80 cm2
Losses Electrical Resistance (RES): 110.00 Ω
Voice Coil Inductance @ 1 kHZ (LE): 0.92 mH
Rated Power: 100.00 W
Musical Power: 200.00 W
Sensitivity @ 1W, 1m: 97.90 dB
