EAE M2-6 ACOUSTIC AMPLIFIER

M2-6 OR M26U ACOUSTIC AMPLIFIER, 4 CHANNELS, MIXER, EFFECTS, BATTERY POWERED AND BLUETOOTH

Elite Acoustics' M2-6 Acoustic Amplifier with 4 chan Mixer, Effects, and Bluetooth features an ergonomically sculpted cabinet to support horizontal or vertical placement; 6½ inch woofer for improved bass response along with a 1 inch silk-dome tweeter to deliver maximum clarity. M2-6 offers 4 input channels and integrated digital effects with an efficient Class D bi-amp. The Master section contains a 3-band EQ, Monitor Volume and stereo AUX input with level control. Selectable Direct Outs or Main mix outputs are provided for system expansion and integration. M2-6 preserves stereo input sources, thereby allowing true stereo playback when used with additional speaker systems. The cabinet is constructed from solid MDF to ensure durability and high fidelity sound, and contains an integrated pole-cup. The included charger doubles as a power supply for non-battery powered operation. M2-6 can also be powered and charged from a car (with included adapter) and once fully charged, the speaker can provide 5-6 hours of playing time. Built-in overcharge/over-drain circuits protect the battery to maximize battery life. Designed and built in USA.

Carrier Bag is sold separately.

Now Available with Lithium Battery upgrade - M26U - Battery Meter works differently on M26U.

FREQUENT QUESTIONS:

1. NO sound from Amp with Chan 1, 2 or 3/4 Inputs but Sound with Bluetooth Streaming

Answer - Check the EFX MIX knob position and make sure it is not Full Clockwise (All WET), set Mix Knob to 12 O'clock and re-check.

2. Battery not charging

Answer - Make sure Battery Switch is in the "Connected" position.

M26U - units with Upgraded Lithium Iron Phosphate (LifePO4) battery.

Battery Meter -

• 3 - Charged. This LED will turn on when battery is fully charged and will turn off once the unit is powered ON after a full. This LED is not part of the battery level meter.
• 2 - normal
• 1 - normal
• LOW - less then 10%
• CHARGE - charging LED will turn off when battery is tully charged.

M2-6 FEATURES

Bi-Amp ultra-efficient class D design, 2-way full spectrum dispersion

Speakers: 6 1/2 inch: woofer, 1 inch soft dome tweeter

+48V Phantom Power

Channel 1: Gain, Mute, Phase, EFX/AUX sena, Paa, Mic/Instr select, Notch Filter, EQ with mid sweep

Channel 2: Gain, Mute, Phase, EFX/AUX send, Pad select, Channel 3/4: Level, EFX send

Master Section:

Volume, Equalizer (High, Mid, Low)

Ettects - Program Select (reverb, chorus, delay), Mix, Decay/ Rate adjustment

Signal and Clip indicators (Channel and Monitor LEDs)

Inputs:

2 mic XLR, 4 Line 1/4", Instrument 1/4", Return 1/4" TRS, Aux 1/8" mini, Bluetooth

Footswitch 1/4" TRS effects bypass, DC input (AC adapter included)

Outputs:

2 XLR, CH 1 & 2 Direct Outs / L & R main mix R output 1/4" (stereo)

Integrated Pole Cup

USB charging only

Dimensions: 13 in. × 11 in. × 9 in.

Weight: 24 Ibs.

Up to 5-6 hours of play time

Designed and assembled in USA
