Akai GX-635D Custom Green Reel-to-Reel Tape Deck – Professionally Restored – Tape & Hubs Included – 1-Year Warranty

Professionally Restored & Calibrated by HQaudios – Fully Tested – Tape & Hubs Included – Backed by Our 1-Year Warranty.

Offered here is a distinctive Akai GX-635D reel-to-reel tape deck finished in a custom green color and professionally restored by our HQaudios technical team.

This is not simply a cleaned or power-tested vintage deck. The machine received extensive mechanical and electronic service, professional record/playback calibration, and extended final testing before being approved for sale.

The tape reel and hubs shown in the photos are included with the purchase.

Key Highlights

• Akai GX-635D stereo reel-to-reel tape deck
• Distinctive Custom Green finish
• Professionally restored and calibrated by HQaudios
• GX head system
• 6-head / 3-motor design
• 4-track, 2-channel stereo / mono operation
• 3¾ IPS and 7½ IPS tape speeds
• Supports reels up to 10.5 inches
• Forward and reverse playback
• Auto-reverse operation
• Factory multi-voltage 110 / 120 / 220 / 240V, 50 / 60Hz
• Tape & Hubs Included
• Actual photos of the unit for sale
• Video testing available
• 1-Year HQaudios Warranty

Professional Restoration & Calibration

This GX-635D has been fully restored and professionally calibrated by our technical team.

Every major operating function was verified, applicable mechanical assemblies were cleaned and re-lubricated, and electronic sections were inspected, serviced, measured, and adjusted for reliable long-term operation.

1. Mechanical Restoration

The tape transport mechanism was extensively serviced, including the reel tables, capstan system, pinch roller assembly, and tension arms.

Old lubricant and accumulated residue were removed from applicable moving assemblies, followed by careful cleaning and re-lubrication using premium synthetic lubricant and damping grease where appropriate.

A new genuine pinch roller and drive belt components were installed.

Brake bands were cleaned, inspected, and balanced for smooth and controlled tape stopping.

The capstan and reel motors were cleaned, inspected, adjusted, and checked for proper operating torque.

Reel movement, tape tension, forward playback, reverse playback, fast-forward, and rewind were tested extensively.

2. Electronic & Audio Restoration

Aging capacitors in the power supply and signal path were replaced as required using quality Nichicon and Panasonic components.

The power supply and audio signal paths were inspected and measured for stable operation.

Bias and EQ circuits were professionally calibrated for both 7½ IPS and 3¾ IPS.

Calibration was performed using professional reference equipment, including MRL test tape and oscilloscope measurements.

Record and playback alignment was adjusted for accurate operation.

Left and right channel levels were carefully matched, with final channel balance calibrated to approximately ±0.2 dB.

Logic relays and associated control circuits were also inspected and serviced.

3. Control System & Auto-Reverse

Switches, relays, control contacts, and related components were cleaned and inspected.

Solder joints in serviced areas were checked and reflowed where required.

The transport control system was repeatedly tested in play, reverse, fast-forward, rewind, stop, and record modes.

The auto-reverse logic and mechanical triggering system were also tested extensively for consistent operation.

4. Cosmetic Restoration

The machine was professionally cleaned and detailed throughout.

The exterior was carefully finished in its distinctive Custom Green color.

Knobs and controls were thoroughly cleaned and polished.

The VU meters were re-illuminated with warm-white LED lighting selected to maintain a classic vintage appearance.

The rear panel was fully cleaned, and RCA/DIN connections were treated with DeoxIT to help maintain clean electrical contact.

5. Final QC & Extended Testing

After restoration and calibration, the machine completed a continuous 3-hour playback and recording test.

During final QC we evaluated:

• Tape speed stability
• Forward and reverse playback
• Recording operation
• Fast-forward and rewind
• Auto-reverse operation
• Reel movement and tape tension
• Channel balance
• VU meter response
• Transport behavior
• Operating temperature
• Overall mechanical stability

The machine was approved for sale only after completing this final testing process.

Technical Specifications

• Track System: 4-track, 2-channel stereo / monaural
  Tape Speeds: 7½ IPS and 3¾ IPS
  Maximum Reel Size: 10.5 inches
  Heads: 6 total – 2 GX record, 2 GX playback, 2 erase
  Motors: 3 – capstan motor plus two reel motors
  Pitch Control: More than ±6%
• Frequency Response with WR Tape:
  30 Hz–27 kHz ±3 dB at 7½ IPS
  30 Hz–21 kHz ±3 dB at 3¾ IPS
• Frequency Response with LN Tape:
  30 Hz–25 kHz ±3 dB at 7½ IPS
  30 Hz–19 kHz ±3 dB at 3¾ IPS
• Wow & Flutter:
  Less than 0.03% WRMS at 7½ IPS
  Less than 0.04% WRMS at 3¾ IPS
• Signal-to-Noise Ratio: Better than 62 dB
  Channel Separation: Better than 55 dB at 1 kHz
  Bias Frequency: 100 kHz
• Inputs: Microphone, Line, DIN
  Outputs: Line, Headphone, DIN
• Power: AC 110 / 120 / 220 / 240V, 50 / 60Hz – Factory Multi-Voltage
  Power Consumption: 70W
  Country of Manufacture: Japan
• Dimensions: Approx. 17.4" W × 19.0" H × 10.1" D
  Weight: Approx. 46.4 lb / 21 kg

Tape & Hubs Included

The tape reel and hubs shown with the machine are included with the purchase.

They complete the classic large-reel presentation and allow the GX-635D to be displayed as shown in our photos.

Cosmetic Condition

This GX-635D presents beautifully in its distinctive Custom Green finish.

The machine has been professionally cleaned and detailed, including the controls, knobs, meters, trim, and rear panel.

As with any vintage component, minor signs of age or previous use may remain.

Please review all photos carefully, as they show the actual machine being offered for sale and are an important part of the cosmetic description.

Technical Condition

This machine has completed our full restoration, calibration, and QC process.

Playback, recording, forward and reverse operation, both tape speeds, fast-forward, rewind, auto-reverse, reel movement, tape tension, GX head operation, meters, controls, switches, and transport logic have been tested.

The machine is fully operational and ready to enjoy.

Sound & Performance

The GX-635D is known for its robust large-reel transport, durable GX head technology, and clean analog presentation.

Following restoration and calibration, this example delivers smooth tape transport, stable playback, accurate channel balance, and the detailed sound that has made the GX-635D a favorite among vintage tape enthusiasts.

Included With Purchase

• Akai GX-635D Custom Green Reel-to-Reel Tape Deck
• Tape Reel
• Hubs
• 1-Year HQaudios Warranty

Please review the listing photos for the exact included accessories.

Actual Photos & Video Testing

All photos in this listing show the actual GX-635D being sold.

Detailed photos are provided so you can inspect the custom finish, tape transport, heads, controls, meters, rear panel, connections, and overall condition.

Video testing has also been performed to demonstrate actual operation and provide additional confidence before purchase.

Professional Packing

Large reel-to-reel decks are heavy and mechanically complex, so proper packing is essential.

This GX-635D will be professionally packed by HQaudios with appropriate protection for the chassis, faceplate, controls, transport components, and exterior surfaces to help ensure safe transit.

1-Year HQaudios Warranty

This Akai GX-635D is backed by our 1-Year HQaudios Warranty.

We stand behind our restoration work and provide after-sale support should assistance be required.

Professionally Restored & Calibrated by HQaudios – Fully Tested – Factory Multi-Voltage – Tape & Hubs Included – Backed by Our 1-Year Warranty.
