JBL AC15 Ultra Compact 2-Way Loudspeaker with 1 x 5.25 LF SINGLE UNIT

JBL AC15 Ultra Compact 2-Way Loudspeaker

The JBL AC15 delivers pristine clarity and punchy midrange response in a compact footprint that punches well above its size class. This 2-way system responds with remarkable immediacy and tonal balance, pairing a 5.25-inch woofer with crisp tweeter definition to give you honest, uncolored sound that translates across genres. The compact dimensions and lightweight construction make integration into existing rigs straightforward, while professional-grade sonics ensure reliable performance in venues, studios, and portable PA applications.

Audio Performance & Coverage

The JBL 2251 woofer (135 mm with 38 mm voice coil) and JBL 201J tweeter (25 mm dome) work together to deliver a frequency response of 90 Hz–18 kHz (±3 dB), with extended reach down to 80 Hz at –10 dB. A 90° × 90° coverage pattern and directivity index of 8 dB ensure consistent sound across the listening area without excessive throw or dead zones.

Build & Connectivity

The multi-ply hardwood enclosure with DuraFlex textured finish withstands road use and environmental stress, meeting Mil-Std 810 and IPx3 weather rating standards. Dual Neutrik Speakon NL4 connectors wired in parallel plus covered barrier strip terminals provide flexible wiring options, while four M8 suspension points (top, bottom, and rear) support secure mounting in any orientation.

Key Features

• 1 × JBL 2251, 135 mm (5.25 in) SFG woofer with 38 mm edge wound voice coil
• 1 × JBL 201J, 25 mm (1 in) voice coil dome tweeter
• Frequency Response (±3 dB): 90 Hz–18 kHz
• Extended Frequency Range (–10 dB): 80 Hz–20 kHz
• System Power Rating: 225 W AES; 150 W / 300 W / 600 W (Continuous/Program/Peak) IEC
• Impedance: 16 ohms
• Coverage Pattern: 90° × 90°; Directivity Index: 8 dB
• Dimensions: 241.3 × 150.3 × 177.8 mm (9.5 × 5.9 × 7.0 in)
• Weight: 4.7 kg (10.5 lb)
• Multi-ply hardwood enclosure with DuraFlex textured finish
• Dual Neutrik Speakon NL4 connectors plus covered barrier strip terminals
• Four M8 suspension points; Mil-Std 810 and IPx3 environmental rating

The AC15 combines professional-grade sonics with road-tested reliability in a format designed for operators who demand transparent playback without compromise.
