Tannoy Cheviot HPD 315A Dual Concentric Speaker Pair

12-Inch Dual Concentric – Professionally Serviced & Fully Tested – 1-Year Warranty

Professionally Serviced, Inspected & Fully Tested by HQaudios – Backed by Our 1-Year Warranty.

1/ About This Pair

Offered here is a pair of Tannoy Cheviot floorstanding loudspeakers fitted with Tannoy's HPD 315A 12-inch Dual Concentric system.

The HPD 315A combines a direct-radiating low-frequency section and high-frequency compression driver concentrically within the same assembly, providing the point-source-style architecture associated with classic Tannoy Dual Concentric loudspeakers.

This pair uses a twin ducted-port bass-reflex enclosure and includes the model's front-accessible Energy and Roll-Off high-frequency controls.

Rear labels on this actual pair identify the system as Cheviot – Type HPD 315A, rated at 60 watts / 8 ohms and manufactured in the United Kingdom.

Both speakers have been inspected, serviced, cleaned, and tested by HQaudios prior to sale.

2/ Key Highlights

• Tannoy Cheviot speaker pair

• HPD 315A 12-inch Dual Concentric system

• 2-way Dual Concentric design

• Twin ducted-port bass-reflex enclosure

• 60 W Continuous Programme power handling

• 8-ohm nominal impedance

• 40 Hz–20 kHz published frequency response

• 89 dB SPL, 1 W / 1 m sensitivity

• 1 kHz crossover frequency

• Energy and Roll-Off high-frequency controls

• Made in the United Kingdom

• Professionally serviced and tested by HQaudios

• 1-Year HQaudios Warranty

3/ Why the Tannoy Cheviot Is Notable

The Cheviot is part of Tannoy's classic HPD-era domestic loudspeaker range and uses the company's well-known Dual Concentric architecture in a relatively compact floorstanding cabinet.

The 12-inch HPD 315A system places the high-frequency compression driver concentrically with the low-frequency cone, allowing both frequency sections to operate from a closely aligned acoustic center.

Adjustable Energy and Roll-Off controls provide additional high-frequency tuning for different rooms, placements, and listening preferences.

4/ HQaudios Inspection, Service & Testing

Before Service

We inspected both Tannoy Cheviot speakers before service, including the HPD 315A driver systems, crossover and control sections, speaker terminals, cabinet surfaces, grilles, and general operating condition.

Our inspection also evaluated overall acoustic operation and the condition of the bass, midrange, and treble reproduction from both speakers.

During Service

Our technicians serviced this pair according to the condition identified during inspection.

We cleaned and detailed the cabinets, front baffles, grille areas, control areas, rear connections, and accessible speaker components as required.

We also checked the HPD 315A driver operation, crossover/control operation, speaker terminals, and connection integrity.

Service Documentation Note:

The available IQC record for this pair documents no replacement parts. This listing therefore does not claim driver replacement, reconing, crossover recapping, or other component replacement unless separately documented.

Final Testing

After service, we tested both speakers together under normal playback conditions.

• Overall acoustic quality checked

• Bass output checked

• Midrange reproduction checked

• Treble reproduction checked

• Energy control operation checked

• Roll-Off control operation checked

• Speaker terminal connections checked

• Left/right consistency evaluated

Final IQC results rated overall acoustic quality, bass, midrange, and treble performance as Good.

5/ Technical Condition

Both speakers have been inspected and tested by HQaudios and were evaluated together under normal stereo playback conditions.

The HPD 315A driver systems, crossover/control sections, Energy and Roll-Off controls, and speaker connections were checked for proper operation.

No replacement parts are claimed for this pair based on the available IQC documentation.

6/ Sound Character

In our listening evaluation, this Cheviot pair delivered the coherent presentation associated with Tannoy's Dual Concentric architecture.

The 12-inch low-frequency section provides substantial scale and weight, while the integrated high-frequency compression driver contributes clarity and presence through the upper range.

The Energy and Roll-Off controls allow additional adjustment of the high-frequency balance to suit room placement and listening preference.

7/ Cosmetic Condition

This pair presents in very good vintage cosmetic condition, with age-related wear visible on close inspection.

The wood-veneer cabinets, black front baffles, grille areas, control sections, and rear panels present well overall.

Light scratches and other normal vintage marks may remain on the cabinet surfaces, including the top, bottom, and side panels.

Please review all listing photographs carefully, as they show the actual pair being offered and form an important part of the cosmetic-condition description.

8/ Specifications

• Brand: Tannoy
• Model: Cheviot
• System Type: HPD 315A Dual Concentric
• Type: 2-Way Bass-Reflex Floorstanding Loudspeaker
• Driver Size: 12 in (315 mm)
• Nominal Impedance: 8 Ohms
• Power Handling: 60 W Continuous Programme
• Frequency Response: 40 Hz–20 kHz
• Sensitivity: 89 dB SPL, 1 W / 1 m
• Crossover Frequency: 1 kHz, 12 dB/octave
• HF Controls: Energy & Roll-Off
• Enclosure: Twin Ducted-Port Bass Reflex
• Country of Manufacture: United Kingdom
• Dimensions: Approx. 17.50 W × 33.00 H × 10.25 D in (445 × 838 × 260 mm)
• Weight: Approx. 55.0 lbs / 25.0 kg each

Actual-unit note: Rear labels on this pair identify the speakers as Tannoy Cheviot systems using HPD 315A and rated at 60W / 8 Ohms.

9/ What's Included

• 1 Pair of Tannoy Cheviot Speakers

• Matching grilles shown in the listing photographs

• 1-Year HQaudios Warranty

Only items clearly shown in the listing photographs or specifically stated above are included.

10/ Suggested Amplification

The Cheviot is an 8-ohm loudspeaker system with a published 60-watt continuous-programme power rating.

We recommend a clean, stable amplifier that is appropriate for an 8-ohm load and operated within the speaker's intended power range.

Avoid sustained amplifier clipping or excessive power.

11/ Basic Use Guide

• Use amplification suitable for an 8-ohm speaker load

• Avoid sustained clipping or excessive power

• Verify speaker wiring and polarity before operation

• Keep the ducted ports unobstructed

• Protect the exposed HPD 315A driver areas during handling

• Contact us if you need assistance with Energy / Roll-Off settings or amplifier matching

12/ Trade-In Program

Do you have vintage audio equipment you would like to trade in?

We welcome trade-in inquiries for vintage receivers, amplifiers, speakers, turntables, cassette decks, reel-to-reel decks, and other classic audio components.

13/ Build Your Vintage System

We can help match this Tannoy Cheviot pair with compatible vintage or modern amplification and source components.

Contact us if you are building a complete system or purchasing multiple compatible components.

14/ Professional Packing & Shipping

Vintage loudspeakers require careful protection during shipment.

We will prepare each speaker with protection focused on:

• Wood-veneer cabinet surfaces

• Cabinet corners and edges

• Grilles and front baffles

• HPD 315A driver areas

• Energy and Roll-Off controls

• Rear terminals

• Minimizing movement during transportation

Specialized freight shipping, palletization, or custom crating may be used when appropriate for the destination and carrier service.

15/ 1-Year HQaudios Warranty

This Tannoy Cheviot pair is backed by our 1-Year HQaudios Warranty covering qualifying functional issues under normal intended home use.

Coverage does not include misuse, physical damage, unauthorized repair or modification, incorrect wiring, amplifier clipping, excessive power, incompatible equipment, moisture exposure, cosmetic wear, or operation outside the intended specifications.

If you experience an operational issue after delivery, please contact us so our team can assist with diagnosis and support.

16/ Important Note for Buyers

Please review all listing photographs carefully, as they show the actual Tannoy Cheviot pair being offered.

The rear labels shown in the photographs confirm the Cheviot model, HPD 315A system designation, 60-watt rating, 8-ohm impedance, and United Kingdom manufacture.

Please contact us if you need assistance with amplifier matching, speaker placement, Energy / Roll-Off settings, wiring, or general system setup.
