THISHEAVYEARTH HIGHER POWER v2

Description

Same great product but now with the most requested features included. Titan presence and depth emulation is now integral to the pedal and gone are the days of the polarity adaptor as HP2 works with center negative and center positive supplies. Lastly, we upgrade from the previous power chip to the latest version bringing along with it the chips improvements for efficiency, low noise, and power.

Higher Power is a 60W class d solid state power amp solution that is a perfect pairing for analog gear or digital modelers.

Don't be fooled, it'll push your 4x12 plenty but it shines on a 1x12 or 2x12 at bedroom levels. The buffer inside sets up your signal with a nice flat response going into the power section so you can drop your favorite preamp pedals in front.

Output impedance of 4-16 ohm.

Designed to be fed with 24VDC 2.7A. It can run on as little as 9v with power scaling down to approximately ~10W. It is not recommended to be powered by your daisy chain or iso-supply. Recommended to be with the supplied power supply that is shipped with the product. Replacement power supplies not available from THE.

Here is a recommended replacement that is readily available through the evil but accessible, Amazon:

Do not use a class d power amp with an attenuator/loadbox. It’s not necessary and it will damage one or the other. Consult your attenuators manual first as I do not know all products and cannot answer for each product that exists out there. For example, Torpedo products specifically state they are safe for solid state amps and that is what I use here.

Power Specifications

9-24VDC - CENTER NEGATIVE

This product can accept up to 24VDC supply input for additional headroom.

Recommended to use 24VDC 3A power supply.

60W @ 4 ohms

Load rating of 4-16 ohms.

Switching System

TRUE BYPASS

Soft click (1.1KGf) mechanical 3PDT.

Controls

Name Location Description

PowerAmp External Controls the overall volume output to the speaker.

Above External Boost presence frequencies.

Below External Boost resonance frequencies.
