Whirlwind IMP Line Level Combiner 2010s
Our users rate Reverb
Whirlwind's IMP-LINE-COMBINER is the perfect solution for when you want to create a mono-mix from a stereo source but still need to keep the original stereo signals isolated. It's perfect for feeding a DAT player or CD into a mono system or single channel on a board. This unit not only combines two line-level signals into one line-level output, but it also compensates for the 6dB of gain that occurs when two in-phase signals are combined. A handy ground-lift switch breaks the shield connection between the inputs.
Specifications
- Frequency response: +/-0.3dB 20Hz-20kHz
- Total harmonic distortion & noise: Less than 0.025% at 1kHz
- Isolation between inputs: Greater Than 42dB
- Insertion loss: -0.6dB, 50 Ohms source impedance -3.8dB, 200 Ohms source impedance
- Output level: -3.8dB with both channels at 0dB sine wave input, in phase
- Maximum input level: +28dBm
- Input impedance: 600 Ohms
- Output impedance: Less than 100 Ohms
