Frequency Response, Line-level Inputs and Outputs +0, –1 dB, 10 Hz to 50 kHz. +0, –3 dB, 5 Hz to 100 kHz. RIAA Equalization Deviation (Phono Input) ± 0.5 dB from 20 Hz to 20 kHz
Distortion (THD & IMD): Line-level Inputs to Line-level Outputs (unity gain) > 0.015%, 20 Hz to 20 kHz @ +4 dBu RIAA Input, Nominal Gain > 0.015%, 20 Hz to 20 kHz @ +4 dBu
Noise Floor (20 kHz Bandwidth, +4 dB level setting, 150Ω source) Unity Gain, with DAW, 2-Track A, and 2-Track B Assigned –86 dBu maximum (all outputs), Monitor A, B, and C Outputs, Studio Output, DAW, 2-Track A, and 2-Track B Outputs –90 dBu typical, Phono Input (nominal 41.8 dB gain @ 1 kHz, inputs shorted) –71 dBu maximum (all outputs), Equivalent Input Noise (E.I.N.): 0.89 μV / –119 dBu maximum
Dynamic Range: Line Inputs 112 dB minimum. Phono Input 93 dB minimum
Common Mode Rejection Ratio: (20 Hz to 20 kHz @ +4 dB level setting) 34 dB minimum, 40 dB typical
Crosstalk: Adjacent Inputs 90 dB @ 1 kHz, Left to Right/Right to Left 70 dB @ 1 kHz, Muted/Level Off 90 dB @ 1 kHz
Trim Control Range: Input Trim Controls (Center Detented) ±10 dB, Output Trim Controls –14 dB to 0 dB
Dim Switch: 0 dB/–20 dB
Rated Input Voltage: Line Inputs (+4 dB Level Setting), +4 dBu/+28 dBu (nominal/maximum), Line Inputs (–10 dB Level Setting), –10 dBu/+14 dBu (nominal/maximum), RIAA Input (@ 1 kHz, nominal gain), 5 mV/79 mV (nominal/maximum)
Rated Output Voltage: All Line-level Outputs (+4dB Level Setting), +4 dBu/+22 dBu (nominal/maximum), All Line-level Outputs (–10 dB Level Setting), –10dBu/+8 dBu (nominal/maximum)
Maximum Voltage Gain: DAW, 2-Track A, and 2-Track B Input to: Monitor A, B, and C Outputs 34 dB. DAW, 2-Track A, 2-Track B, and Phones Amp Outputs 24 dB,
Studio Output 34 dB, Phones 1 and 2 Outputs 34 dB (output loaded @ 100 kΩ), DAW Phone Mix Input to Phones Amp Outputs 14 dB, Studio Output 24 dB,
Phones 1 and 2 Outputs 24 dB (output loaded @ 100 kΩ), Phono Input @ 1 kHz to: Monitor A, B, and C Outputs 67.8 dB, DAW, 2-Track A, 2-Track B, and
Phones Amp Outputs 57.8 dB, Studio Output 67.8 dB, Phones 1 and 2 Outputs 67.8 dB (output loaded @ 100 kΩ)
Input Impedance: Line Input 24 kΩ balanced, 12 kΩ unbalanced, Phono Input 47 kΩ || 220 pF
Output Impedance: Line Output 300Ω balanced, 150Ω unbalanced, Headphone Output 150Ω
Price$349.99
