Celestion TF0615MR 6" Pro Midrange Closed Sealed Back Speaker 100W Woofer 8-Ohms
Features
• 6" mid-range driver providing 97dB sensitivity and 50Wrms (AES standard) power handling
• 1.5" high temperature copper voice coil wound on polyimide former for increased reliability
• Very compact model suitable for use in 3-way systems
• Optimised to deliver detailed reproduction of mid-range frequencies
• Closed back chassis simplifies cabinet manufacture, eliminating need for separate mid-range enclosure
Specifications
Chassis Type
Pressed steel
Coil Material
Round copper
Cone Material
Kevlar loaded paper
Former Material
Polyimide
Frequency Range
500 to 5000Hz
Magnet Type
Ferrite
Nominal Diameter
152mm / 5.98"
Nominal Impedance
8Ohms
Sensitivity
97dB
Surround Material
Treated paper
Suspension
Single
Voice Coil Diameter
1.5" / 38.1mm
Small Signal Parameters
Fs: 500Hz Re: 5.7Ohms Le (at 1kHz) 0.27mH
Mounting Information: Diameter
7.01" / 178.05mm
Mounting Information: Overall Depth
74mm / 2.91"
Mounting Information: Cut-Out Diameter
147mm / 5.79"
Mounting Information: Slot Dimensions
Diameter: 4.3mm / 0.17"
Mounting Information: Number Of Slots
4
Mounting Information: Pcd Range
168.5mm / 6.63"
Power Rating
50Wrms
Weight
Mounting: 1.4kg / 3.09lbs Magnet: 1.06lbs / 0.48kg
Price$52.50
Free Shipping
from Brooklyn, NY
14-Day Return Policy
Enjoy peace of mind with your new gear
1
10+ in stock
