The Allen & Heath ZED-6FX adds built-in multi-model effects to the compact ZED-6 platform. With 2 mono mic/line channels and 2 stereo line channels, GSPre preamps, Hi-Z guitar DI inputs, and a dedicated FX send per channel feeding stereo reverbs, delays, and special effects, the ZED-6FX is ideal for performers and content creators who need onboard processing without external gear.

Inputs and Outputs

• 2 mono mic/line channels with XLR and 1/4" TRS inputs
• 2 stereo line channels (4 x 1/4" TRS inputs)
• Hi-Z instrument inputs on channels 1-2 for direct guitar/bass connection
• 1 x post-fade FX send per channel
• 1 x 1/4" FX Out/Mute output
• Main stereo output on XLR L/R
• 1/4" headphone output
• +48V global phantom power

EQ and Processing

• 2-band EQ on all channels
• Built-in stereo effects: multi-model reverbs, delays, and special FX

Specifications

• Metering: L/R peak meters
• Controls: Rotary level (no faders)
• Dimensions: 249 x 88.9 x 236.4 mm (9.8" x 3.5" x 9.3") W x H x D
• Weight: 1.36 kg / 3.0 lbs
• Power: Internal PSU with IEC C5 connector

In the Box

• ZED-6FX Mixer
• IEC C5 Mains Power Cable
• User Guide
