OXI INSTRUMENTS Split 2HP - Expander Modular Synthesizer

• MIDI extension for ONE & ONE MkII
• 3x MIDI Out (TRS)
• 1x MIDI Thru (TRS)
• Connection to ONE MkII via TRS cable
• passive module, no power consumption
• 27mm installation depth
• incl. TRS-TRS cable


Split 2HP from Oxi Instruments is an efficient way to expand the MIDI connections of the ONE MkII sequencer. The compact module is first installed in the Eurorack Case and connected to the MIDI output of the ONE MkII sequencer using the supplied cable. The MIDI output triples with the MIDI expander to three ports in TRS format. A Thru socket is also available. The latter is useful in setups where the ONE MkII is not the master sequencer. The three outputs can be selected as ports in the ONE MkII and each have 16 MIDI channels.
