HK Audio LINEAR-5-MK2-118S-HPA Linear 5 MK II Series 3000-Watt 18-Inch HP Active Sub DSP Out 4 EQ Presets Network

Most powerful subwoofer in the LINEAR 5 MK II series with significantly more energy in the low-end range. PowerCon connections with links for easy cabling.

Technical Data

• Max. SPL @ 10% THD: 130 dB half space (36 Hz – 100 Hz averaged).
• Max. SPL Peak @ 10% THD: 131 dB half space.
• Frequency response +/-3 dB: 36 Hz – X-over.
• Frequency response -10 dB: 33 Hz – X-over.
• Power amp output (RMS/Peak): 1,500 / 3,000 W.
• Amplifier type: Class D.
• LF driver: 1 x 18", 4" voice coil.
• Low-/Mid speaker: -
• HF driver: -
• Horn directivity: -
• Active crossover frequency: -
• Maximum input level: +20 dBu.
• Analog inputs: 2 x XLR combo balanced.
• Analog Thru: 2 x XLR balanced.
• DSP Out: 1 x XLR balanced.
• Network port: Ethercon RJ45, 1 x In, 1 x Thru.
• Filter presets: Front, Cardioid 1:1 vertical, Cardioid 2:1 vertical, Remote.
• Remote software: DSP CONTROL (Windows, Mac OS).
• DSP functions: Fully parametric 10-band EQ with variable filter characteristics, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute.
• Sample rate: 48 kHz.
• System latency: ≤ 2.6 ms.
• Mains connector: 1 x Powercon NAC3 In, 1 x Powercon NAC3 Thru, 100–240 V.
• Power consumption: 2.5 A / 100–240 V nominal according to EN 62368-1.
• Angles up (Monitor angle): -
• Pole mount: 1 x M20.
• Rigging points: -
• Carrying handles: 4 x HK Audio MultiGrip.
• Housing: Birch multiplex.
• Finish: Black acrylic enamel.
• Front grille: 2 mm metal grille backed with black acoustic foam.
