SPECS

Neck type BTB55 pc Maple/Walnut w/Graphite reinforcement rods Neck-through

Top/back/body Walnut top Ash/Okoume wing body

Fretboard Rosewood fretboard Abalone dot inlay

Fret Medium Stainless Steel frets

Number of frets 24 (+ zero fret)

Bridge MR5 bridge

String space 19mm

Neck pickup Bartolini® BH2 neck pickup Passive

Bridge pickup Bartolini® BH2 bridge pickup Passive

Equaliser Ibanez Custom Electronics 3-band EQ w/ 3-way Mid frequency switch

Factory tuning 1G,2D,3A,4E,5B

Strings D'Addario® NYXL45130SL

String gauge .045/.065/.080/.100/.130

Hardware color Cosmo black

NECK DIMENSIONS

Scale : 889mm/35"

a : Width 47mm at NUT

b : Width 76mm at 24F

c : Thickness 20mm at 1F

d : Thickness 22mm at 12F

Radius : 400mmR

FEATURES

5pc Maple/Walnut neck with Graphite reinforcement rods

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.The Graphite reinforcement rods provides massive sustain and excellent stability.

Rosewood fretboard

Rosewood provides a well-balanced solid tone with a focused mid range.

Ibanez Custom Electronics 3-band EQ w/Mid frequency switch

Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.

Bartolini® BH2 pickups

The Bartolini® BH2 pickups provide a tight bottom-end, punchy mid-range, and smooth response. The dual-coil style configuration maximizes articulation and a long blade pole piece widens the magnetic field, providing balanced string-to-string pickup response.

MR5 bridge

The Mono-Rail V is the ultimate bridge for bass string isolation. Each bridge is independently and securely locked down to the body for maximum vibration transfer without interference.
