Quad 510 mono power amplifier - Used

This used Quad 510 is a single channel 130 watt amplifier for 19inch 2U rack mounting. This Amp has been tested and works. It features some signs of cosmetic wear from previous use. The balanced signal input is suitable for bridging 600 ohm lines, 0.775 Vrms, with a lockable gain control. The output is isolated and provides up to 130 watts into almost any impedance from 2 to 75 ohm, the choice being determined by a plug-in card.

We have multiple of this item, please contact us to make sure the unit pictured is the unit you will be sent.

The 510 is thus highly versatile and can be used either singly or in groups to provide virtually any power into any load. The amplifier is fully protected and virtually proof against mis-use. No harm can be caused by factors such as gross overload, continuous operation or short circuits, heavy reactive loading, inadequate ventilation etc.

• Power output: 135W into 8Ω (mono)
• Frequency response: 30Hz to 20kHz
• Total harmonic distortion: 0.1%
• Input sensitivity: 0.775V
• Signal to noise ratio: 115dB
• Speaker load impedance: 2Ω (minimum)
• Dimensions: 482.6 x 88 x 310mm
• Weight: 12.5kg
