Boutique Class A Tone In A Digital World

Designed, engineered & made with pride in Great Britain, the L5-STUDIO is the first – and only – Single-Ended Class ‘A’ tube amplifier that has the ability to interface directly with any DAW, across any platform, using Laney’s unique T-USB technology. The L5-Studio is ideal for home and studio use, it can be run silently using the high-quality internal dummy load which means it can be used at any time day or night. The L5-Studio delivers an amazing array of clean, crisp, dynamic and open guitar tones. Whatever your style, play through a Lionheart and you’ll be amazed at how it reacts to your touch.

Single-ended (SE) power output stages are probably the simplest form of power amplifier design and usually used for relatively small amplifiers, e.g., less than 15W. SE can only operate cleanly in Class A mode and produce an output rich in even harmonic distortion.

The T-USB interface supplies both a dry signal and the processed signal – split left and right to your DAW – directly into either your PC/MAC or iPad*.

In order to let you operate your tube amplifier silently we have included an internal dummy load. This means that you can use your amplifier without the need to connect an external load (speaker) to it, without fear of damaging your amplifier.

On-board studio quality reverb. Reverb gives you a sense of the space that you are in. A dry guitar signal can sound a little dull. Adding the right about of reverb provides the guitar signal with ambience and brings it to life.

Features

• Cabinet design : marine grade plywood cabinet with retro banding strip, leather strap handle
• Channels : clean & drive
• Channel controls : clean volume, drive & drive volume
• Class : single-ended class "a"
• Di socket : balanced di output with speaker emulation
• Equalisation : passive bass, middle, treble & tone
• Fx loop(s) : (series/switchable level)
• Inputs : 2x jack, hi & lo
• Output valves : 1x el84
• Packed dimensions (hxwxd mm) : 189 x 419 x 183
• Power : 5w & 0.5w rms
• Preamp valves : 3 x 12ax7
• Reverb : digital hi quality studio reverb
• Speaker connections : 0.5w & 5w output jacks
• Unit dims - for int. Case (hxwxd mm) : 90 x 420 x 185
• Cover : supplied with custom embroidered slip cover
• Master section : global eq, reverb and tone controls
• Re-amp enabled : yes - re-amp functionality
• Usb connectivity : t-usb usb connectivity
