BOSS SD-1W Super Overdrive Waza Craft Pedal

The BOSS SD-1W Super Overdrive is a premium Waza Craft redesign of BOSS's legendary SD-1, passionately engineered by master craftsmen in Japan to deliver superior tone that honors the original's 40-year legacy while expanding its tonal capabilities. The Waza Craft line represents the pinnacle of BOSS design and craftsmanship—featuring all-discrete analog circuitry, carefully selected premium components, refined circuit topology, and meticulous attention to detail that elevates every aspect of the playing experience.

The SD-1W features dual sound modes accessible via a front-panel toggle switch. Standard mode preserves the classic SD-1 tone that players have trusted for decades, faithfully reproducing the warm asymmetrical clipping character and mid-focused overdrive of the original circuit. Custom mode expands beyond the classic design, widening the tonal range and gain structure for more versatility while retaining the organic, touch-sensitive feel that defines great overdrive pedals. In both modes, the SD-1W is highly responsive to picking dynamics and guitar volume changes.

Made in Japan with all-discrete analog components and a premium buffered bypass circuit, the SD-1W is the SD-1 for players who demand nothing less than the best. Whether used in Standard mode for classic tube-like warmth or in Custom mode for extended tonal exploration, the SD-1W rewards expressive playing and responds like a living, breathing extension of the instrument. It is backed by the BOSS five-year warranty.

Key Features

• All-Discrete Analog Circuitry: Waza Craft construction with carefully selected premium analog components for refined tone quality
• Dual Sound Modes: Standard mode preserves classic SD-1 tone; Custom mode expands tonal range and gain structure
• Made in Japan: Handcrafted by BOSS master engineers with the Waza Craft philosophy of superior tone
• Highly Responsive: Exceptional sensitivity to picking dynamics and guitar volume adjustments
• Front-Panel Mode Switch: Instant access to Standard or Custom voicing without needing to remove the pedal from your board
• DRIVE, TONE, LEVEL Controls: Classic three-knob layout for intuitive tone shaping
• BOSS Five-Year Warranty: Premium build quality backed by BOSS's industry-leading warranty

Technical Specifications

• Nominal Input Level: -20 dBu
• Input Impedance: 1 M ohm
• Nominal Output Level: -20 dBu
• Output Impedance: 1 k ohm
• Recommended Load Impedance: 10 k ohms or greater
• Bypass: Buffered bypass
• Controls: Pedal switch, Mode switch, LEVEL knob, TONE knob, DRIVE knob
• Indicator: CHECK indicator (battery status)
• Connectors: INPUT jack (1/4-inch phone), OUTPUT jack (1/4-inch phone), DC IN jack
• Power Supply: Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22); AC adaptor (PSA series, sold separately)
• Current Draw: 15 mA
• Battery Life: Approx. 25 hours (carbon-zinc); Approx. 42 hours (alkaline)
• Width: 73 mm (2-7/8 inches)
• Depth: 129 mm (5-1/8 inches)
• Height: 59 mm (2-3/8 inches)
• Weight: 430 g (1 lb, including battery)
