Specifications

Keyboard

61 keys with Velocity

Sounds

Factory:

More than 950 (including Stereo Piano and GM 2 Sounds)

64 Drum Kits

User:

256 Sounds

128 Drum Kits

Tone Generator:

128 Oscillators (max polyphony 128 voices)- Filters with Resonance

PCM User Memory:

96 MB

Effects & EQ:

4 Stereo Master FX / 125 Effects types

Three band EQ for each track – Articulations

Limiter – Master 4 band Parametric EQ

Others:

Dynamic Nuance Control (DNC) Technology

Full editing of Sounds and Drum Kits

Realtime sound control using assignable Switches

Controllers:

Joystick – 2 Assignable Switches

Styles

Factory:

More than 360 preloaded Styles, freely reconfigurable

User:

Up to 1,200 available Style locations including the Favorite/User banks

Structure:

Eight Style tracks, 4 Single Touch Settings and one Style Performance per Style

Style controls:

3 Intros, 4 Variations, 4 Fills, Break, 3 Endings, Autofill, Synchro Start/Stop, Tap Tempo/Reset,

Manual Bass, Bass Inversion, Memory, Accompaniment Mute, Snare & Kick Designation,

STS Mode – Chord Sequencer

Others:

Guitar Mode 2,

Parallel and Fixed NTT, Style Record with Step Record, Track and Event Edit functions

Performance/STS

320 Realtime Performance locations

STS: Memorize Realtime tracks

Up to 4 x Styles, up to 4 x SongBook entries

My Setting special Performance

Realtime Tracks

Four Keyboard tracks (Upper 1, 2, 3, Lower)

Pads

4 Pad tracks + Stop button – Pad Record

Song Play

Single Player with Select, Start/Stop, Home, Rewind and Fast Forward controls

Jukebox function – Compatible with SMF (formats 0 and 1) and MP3 with Vocal Remover –

Lyrics (compatible with CDG), Score, Marker

Display

7” 800 x 480 TFT Graphical Color TouchView

Sequencer

Quick Record (Backing Sequence), Multitrack and Step Record functions

Full featured sequencer – 16 tracks – Up to 100.000 events – SMF format

Song Book

Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes – User-definable custom lists – Filtering options

Search

Style, Song, Performance, SongBook, Sound and Lyrics TXT

Compatibility for Sound Data

“i-Series“: Styles only

“Pa series”: Style, Performance, Sound, PCM, Song, SongBook and Pad

General Controls

Master Volume, Real Time-Acc/Seq Balance Volume, Ensemble, Octave Transpose, Master Transpose, Fade In/Out, Tempo Lock, Style Change – Quarter Tone Arabic Scale, User Scale memorized inside Performance/STS, Search, Lyrics, Score, Maker, Dial, Tempo, Metronome, Split

Connections

Control Inputs:

Damper Pedal, Assignable Pedal/Footswitch

Line Out:

Unbalanced Jack Left/Mono, Right, Headphones

Line In:

2 Unbalanced Line In Jacks

MIDI:

In, Out Midi connectors – USB to Midi using the USB Device port

Individual track assignment – 8 user definable MIDI Preset

USB:

Type A (TO DEVICE) x 1: 2.0 Hi Speed

Type B (TO HOST) x 1: 2.0 Hi Speed

Speaker System

Amplification:

15W x 2

Speakers:

100 mm x 2 Double Cone Speakers in Bass Reflex Box

Power

Power Supply:

AC 100-240 V

Power Consumption:

20 Watt

Dimensions (W x D x H):

1,030 x 378 x 127 mm without music rest

Weight

11 kg

Accessories

Owner’s Manual, Music Stand, Accessory DVD (It includes Video Manuals), AC Cable
